Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 470 x 470 x 464 mm | |
|---|---|---|
| Seat diameter | 413 mm | |
| Seat height from floor | 464 mm | |
| Seat padding thickness | 76 mm | |
| Base outer diameter | 413 mm | |
| Base vertical U-cutout width | 152 mm | |
| Base wall thickness | 3 mm | |
| Floor contact pad diameter | 19 mm | |
| Open clearance under seat | 388 mm | |
| Seat side upholstery wrap height | 127 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net product weight | 7 kg | |
|---|---|---|
| Recommended static weight capacity | 136 kg | |
| Seating capacity | 1 person | |
| Seat foam density | 35 kg/m³ | |
| Foam rebound rate | 55% | |
| Metal base static load rating | 181 kg | |
| Upholstery abrasion resistance | 30000 Martindale cycles | |
| Floor protection load rating per pad | 68 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat upholstery | Black-and-white speckled boucle polyester fabric | |
|---|---|---|
| Seat core padding | High-density polyurethane foam | |
| Internal seat support board | 12 mm thick plywood | |
| Support base | Matte black powder-coated steel tube | |
| Base surface finish | Scratch-resistant matte black powder coat | |
| Floor contact glides | Non-marking rubber pads | |
| Upholstery attachment | Stapled fabric fixed to internal plywood seat board | |
| Seam stitching | Matching thread with 8 mm stitch pitch | |
| Anti-corrosion base treatment | Phosphate pre-treatment under powder coat | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Fixed static seating | Non-adjustable rigid base for stable stationary seating | |
|---|---|---|
| Multi-use surface support | Supports use as footrest, extra seating or vanity seat | |
| Floor protection | Rubber glides prevent scuffs on hard flooring | |
| Easy maintenance | Spot-cleanable boucle upholstery for domestic care | |
| Leveling stability | Fixed base with evenly weighted contact points | |
| Space-efficient footprint | Compact round form fits small vanity nooks and entryways | |
| Upholstery breathability | Textured boucle weave allows air circulation for seating comfort | |
| Scratch-resistant base | Powder coat finish resists daily scuffs and wear | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential vanity nooks | Low seat height aligns with standard makeup vanity tables | |
|---|---|---|
| Entryway accent seating | Compact footprint provides temporary seating in narrow hallways | |
| Bedroom extra seating | Works as footrest at bed foot or side seat for dressing areas | |
| Small apartment living spaces | Space-efficient form adds flexible seating without taking excess floor area | |
| Walk-in closet dressing areas | Short height fits under closet shelving for shoe changing use | |
| Commercial boutique fitting rooms | Contemporary design fits modern retail fitting area seating | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Stability testing for domestic seating furniture | |
|---|---|---|
| EN 12520:2015 | Strength, durability and safety for domestic seating |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements applicable to domestic metal furniture | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material formaldehyde emission limits | |
| GB/T 19804-2005 | Stability test requirements for seating furniture without backrests |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements applicable to domestic metal furniture; 2. GB 18584-2001: Indoor decoration material formaldehyde emission limits; 3. GB/T 19804-2005: Stability test requirements for seating furniture without backrests; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
