Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 510 x 510 x 460 mm | |
|---|---|---|
| Lid diameter | 510 mm | |
| Seat/lid thickness | 80 mm | |
| Lower base band height | 380 mm | |
| Internal storage diameter | 450 mm | |
| Internal storage depth | 350 mm | |
| Pull tab length | 30 mm | |
| Floor contact base diameter | 490 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Net product weight | 8 kg | |
|---|---|---|
| Static seat load capacity | 150 kg | |
| Internal storage volume | 42 L | |
| Recommended maximum seated user weight | 110 kg | |
| Foam padding density | 25D | |
| Fabric abrasion resistance | 15000 double rubs | |
| Structural frame static load rating | 200 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upper lid upholstery | Light beige woven polyester fabric | |
|---|---|---|
| Lower base upholstery | Charcoal black woven polyester fabric | |
| Seat padding | 25D high-resilience polyurethane foam | |
| Internal structural frame | 12mm thick MDF panels | |
| Lid underside support | 9mm thick plywood ring | |
| Fabric pull tab | Matching black webbing | |
| Base bottom layer | Non-woven fabric dust cover | |
| Seam stitching | Polyester thread with 8mm stitch pitch | |
| Upholstery adhesive | Low-VOC water-based contact cement | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Storage access | Lift-off upholstered lid operated via front fabric pull tab | |
|---|---|---|
| Seating function | Padded flat top supports casual extra seating for one adult | |
| Footrest function | Low 460mm profile suitable for use as a living room footrest | |
| Surface use | Flat stable top supports lightweight trays or small decor items | |
| Lid fit | Recessed lid lip prevents sliding when placed on the base | |
| Floor protection | Smooth upholstered base eliminates sharp edges to prevent floor scratching | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Living room application | Positioned in front of sofas as a footrest or extra casual seating | |
|---|---|---|
| Bedroom application | Placed at bedside or closet nook for blanket and accessory storage | |
| Small apartment use | Serves dual storage and seating function to maximize limited floor space | |
| Home office use | Used as an under-desk footrest or guest seating near workstations | |
| Entryway use | Placed near entry doors for temporary shoe removal seating and small item storage |
EU Market Access Requirements* EN Standards
| Furniture safety seating | EN 12520:2015 | |
|---|---|---|
| Formaldehyde emission | EN 13986:2004+A1:2015 |
Standards applicable to China-market projects
| Upholstered furniture safety | GB 28007 | |
|---|---|---|
| Formaldehyde emission | GB 18584 | |
| Fabric colorfastness | GB/T 3920 |
This product must meet the following technical requirements: 1. Upholstered furniture safety: GB 28007; 2. Formaldehyde emission: GB 18584; 3. Fabric colorfastness: GB/T 3920; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
