Automatic mm / inch conversion · Core engineering specifications
| Overall table dimensions | 2800 x 900 x 750 mm | |
|---|---|---|
| Integrated recessed tea drain tray dimensions | 1200 x 400 mm | |
| Attached side tea prep cabinet dimensions | 750 x 450 x 650 mm | |
| Tabletop panel thickness | 12 mm | |
| Support leg vertical fluted panel thickness | 50 mm | |
| Tabletop edge metal trim width | 20 mm | |
| Knee clearance height under table | 680 mm | |
| Table corner radius | 50 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 300 kg | |
|---|---|---|
| Table net weight (without chairs/cabinet) | 120 kg | |
| Tea tray drain flow rate | 1.5 L/min | |
| Sintered stone surface heat resistance | 1200 °C | |
| Surface scratch resistance (Mohs scale) | 6 | |
| Recommended service life (commercial use) | 10 years | |
| Supported user weight per seating position | 150 kg | |
| Seating capacity per side | 3 seats per long side | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main tabletop | 12mm full-body sintered stone, light marble-pattern finish, stain-resistant | |
|---|---|---|
| Integrated tea drain tray | Black slotted natural bluestone, recessed flush with tabletop | |
| Edge trim | 20mm wide brushed dark stainless steel, rounded edge profile | |
| Support legs | A3 grade carbon steel with dark bronze powder-coat finish, vertical fluted detailing | |
| Side prep cabinet countertop | Dark sintered stone matching table edge finish, heat-resistant for kettles | |
| Side cabinet body | Low-emission engineered wood with matte dark laminate finish | |
| Frame understructure | 40x40mm square carbon steel cross-bracing, anti-rust treated | |
| Leveling feet | Adjustable stainless steel glide feet, 10mm adjustment range | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Integrated tea drainage system | Recessed slotted tray connects to hidden drain pipe for waste water removal | |
|---|---|---|
| Side prep cabinet integration | Attached adjacent cabinet holds automatic water boiler, sterilizer and teaware storage | |
| Fixed stable structure | Floor-mounted support legs with no moving parts, designed for permanent reception placement | |
| Cable management for appliances | Hidden channel routes power cords from cabinet kettles to floor outlets without exposed wiring | |
| Stain-resistant tabletop | Non-porous sintered stone surface allows tea spills to be wiped clean without residue | |
| Compatible chair configuration | Designed to pair with 6 cantilever metal-framed upholstered armchairs arranged around perimeter | |
| Heat-resistant work surface | Tabletop supports direct placement of hot teapots and boiling kettles without surface damage | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Office executive reception areas | Serves as formal tea ceremony meeting space for hosting VIP clients and internal discussions | |
|---|---|---|
| Commercial tea room venues | Provides dedicated multi-seat service surface for traditional tea tasting events and small gatherings | |
| High-end residential study/living areas | Functions as premium multi-use table for home tea gatherings and casual meetings | |
| Hotel private lounge areas | Seats 6 guests for welcome tea service in executive lounge or private dining suites | |
| Recommended configuration | Pair with 6 matching cantilever upholstered armchairs and fully automatic tea boiler set |
EU Market Access Requirements* EN Standards
| Furniture surface durability | EN 15185:2011 Furniture - Assessment of surface resistance to abrasion, applicable for tabletop wear testing | |
|---|---|---|
| Furniture stability | EN 15372:2016 Furniture - Strength, durability and safety for non-domestic tables | |
| Stone surface heat resistance | EN 14617:2016 Agglomerated stone - Test methods for thermal shock resistance |
Standards applicable to China-market projects
| Table surface safety | GB/T 3324General technical requirements for wooden furniture, applicable for cabinet and supporting structure | |
|---|---|---|
| Stone surface performance | GB/T 41006Sintered stone for furniture, applicable for tabletop material acceptance | |
| Metal frame durability | GB/T 3325Metal furniture general technical requirements, applicable for steel support structure | |
| Formaldehyde emission | GB 18584Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wooden furniture |
This product must meet the following technical requirements: 1. Table surface safety: GB/T 3324General technical requirements for wooden furniture, applicable for cabinet and supporting structure; 2. Stone surface performance: GB/T 41006Sintered stone for furniture, applicable for tabletop material acceptance; 3. Metal frame durability: GB/T 3325Metal furniture general technical requirements, applicable for steel support structure; 4. Formaldehyde emission: GB 18584Indoor decorating and refurbishing materials - Limit of formaldehyde emission from wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
