Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1600 × 750 × 750 mm | |
|---|---|---|
| Tabletop thickness | 15 mm | |
| Integrated tea tray dimensions | 600 x 250 x 20 mm | |
| Cylindrical right pedestal diameter | 500 mm | |
| Rectangular left pedestal width | 350 mm | |
| Table overhang (front/back) | 50 mm | |
| Seated knee clearance height | 680 mm | |
| Gold trim strip width | 15 mm | |
| Table edge radius (rounded end) | 375 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 85 kg | |
|---|---|---|
| Tabletop static load capacity | 150 kg | |
| Tea tray drainage capacity | 2 L | |
| Recommended seating capacity | 4 persons | |
| Edge impact resistance | 1.5 J | |
| Surface wear resistance | 4000 cycles | |
| Gold trim adhesion rating | Grade 1 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop | Glazed white sintered stone with grey marble veining, polished finish, sealed rounded edge | |
|---|---|---|
| Integrated tea tray | Black natural slate, grooved surface for water drainage | |
| Structural pedestals | E1 grade medium-density fiberboard, white painted finish, gold metal accent trim | |
| Accent hardware | Stainless steel with PVD titanium gold plating, polished finish | |
| Edge trim | T-shaped gold metal profile, bonded to tabletop edge for impact protection | |
| Internal support frame | 1.2mm thick carbon steel square tube, powder coated black, connecting both pedestals under tabletop | |
| Drainage fitting | Food-grade plastic water outlet with silicone seal, positioned on right cylindrical pedestal | |
| Surface coating on pedestals | Matte polyurethane paint, scratch-resistant clear top coat | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6 finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated tea preparation surface | Recessed slate tea tray factory-fitted into tabletop, with dedicated drainage port to route waste water to under-table storage bucket | |
|---|---|---|
| Waste water access | Side-mounted drain port on right cylindrical pedestal with quick-connect fitting, supporting standard 10mm diameter drain hose | |
| Double pedestal support | Closed rectangular left pedestal and fluted cylindrical right pedestal forming stable leg-free open knee space along the front long edge | |
| Stain-resistant tabletop | Non-porous sintered stone surface, resistant to tea stains and hot water spills up to 120°C, no sealing required for daily use | |
| Decorative illumination compatibility | Right cylindrical pedestal designed to support optional LED ambient light strip behind gold trim band for indirect under-table lighting | |
| Leveling adjustment | Concealed adjustable feet under both pedestals, 10mm adjustment range to compensate for uneven wood flooring | |
| Modular assembly | Tabletop and two pedestals shipped as separate components for on-site assembly with bolted metal connection brackets | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Number of shipping cartons | 3 | |
|---|---|---|
| Tabletop carton dimensions | 1700 x 850 x 100 mm | |
| Pedestal carton dimensions | 600 x 600 x 800 mm | |
| Total shipping gross weight | 105 kg | |
| Total shipping volume | 0.43 CBM | |
| On-site assembly time | 40 minutes | |
| 20ft GP container loading quantity | 82 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential tea room | Suited for dedicated home tea rooms and open-plan living areas, light luxury finish complements New Chinese and modern minimalist interior decor | |
|---|---|---|
| Executive office reception | Suitable for manager office reception areas, providing formal tea service space for hosting clients without separate side tables | |
| Club lounge seating area | Appropriate for high-end club and private lounge spaces, providing dedicated tea preparation surface for guest service | |
| Open-plan apartment dining space | Usable as compact dining table for small households, integrated tea tray eliminates need for separate tea service accessories | |
| Recommended supporting seating | Pairs with 450mm seat height dining/tea chairs with metal frames, matching the gold and taupe chair style shown in product imagery |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for metal furniture | |
| GB 6566-2010 | Limits of radionuclides in building materials |
This product must meet the following technical requirements: 1. GB 18584-2001: Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture; 2. GB/T 3324-2017: General technical requirements for metal furniture; 3. GB 6566-2010: Limits of radionuclides in building materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
