Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (L×W×H) | 1200 × 650 × 500 mm | |
|---|---|---|
| Tabletop thickness | 12 mm | |
| Embedded tea appliance cutout size | 370 × 230 mm | |
| Tea tray placement area size | 600 × 300 mm | |
| Lower storage shelf clearance from floor | 180 mm | |
| Leg assembly width per unit | 200 mm | |
| Tabletop overhang around frame | 20 mm | |
| Metal frame tube wall thickness | 1.5 mm | |
| Knee clearance height under tabletop edge | 420 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total table static distributed load capacity | 150 kg | |
|---|---|---|
| Integrated electric kettle capacity | 1 L | |
| Sterilizer pot usable volume | 0.8 L | |
| Tabletop heat resistance temperature | 1200 °C | |
| Tabletop surface abrasion resistance | 6000 revolutions | |
| Unit net weight (without appliances) | 38 kg | |
| Recommended serving capacity | 4 persons | |
| Frame anti-rust coating durability | 10 years | |
| Lower shelf load surface dimensions | 1100 × 550 mm | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Primary tabletop | 12mm white marble-veined sintered stone, polished finish, black edge trim | |
|---|---|---|
| Structural frame | Black powder-coated carbon steel tubing and solid panels, matte finish | |
| Angled leg slats | 1.5mm wall thickness round carbon steel tubes, welded to perimeter base frame | |
| Central leg support panels | 2mm thick matte black steel sheet, welded to frame for torsional rigidity | |
| Lower storage shelf | Matte black steel panel, perforated or solid, fixed to perimeter cross braces | |
| Integrated kettle and sterilizer | Food-grade 304 stainless steel, electric heating elements, insulated handles | |
| Appliance mounting base | Heat-resistant black phenolic composite recessed insert, sealed to tabletop | |
| Assembly hardware | Zinc-plated steel bolts and lock washers, pre-threaded frame mounting points | |
| Surface coating on frame | Epoxy-polyester hybrid powder coat, 80μm thickness, scratch-resistant | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Integrated tea station function | Recessed electric kettle and sterilizer with automatic top water feed, boil-dry protection | |
|---|---|---|
| Lower shelf storage function | Fixed open steel shelf accommodates clean/waste water buckets, tea canisters and spare teaware | |
| Assembly configuration | Knock-down flat-pack design with 3 leg assemblies attached to tabletop via bolted connections | |
| Surface use function | Stain-resistant non-porous sintered stone top supports direct placement of hot a kettles and teaware without heat pads | |
| Frame stability function | Dual A-frame geometric leg structure with perimeter base bracing prevents lateral wobble on even floors | |
| Tea service layout function | Dedicated flat tea tray zone separate from appliance zone prevents cross-contamination of boiling water and serving ware | |
| Floor protection function | Hidden non-marking PP foot pads under each frame corner prevent scuffing on hard floors and carpet | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Office reception area | Fits 3seat reception sofas for guest tea service during business meetings | |
|---|---|---|
| Modern living room | Serves as a dual-function coffee table and gongfu tea station for home tea enthusiasts | |
| Tea room and lounge | Provides dedicated tea preparation surface for small casual tea tasting sessions for 4 users | |
| Executive private office | Placed adjacent to visitor seating for informal tea receptions with business partners | |
| Small apartment open-plan space | Combines coffee table and dedicated tea table function to reduce redundant furniture footprint |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Strength, durability and safety requirements for domestic and contract tables | |
|---|---|---|
| EN 60335-1:2012 | Safety standard for household electrical appliances covering integrated tea heating units | |
| EN 13722:2004 | Performance requirements for metal furniture frames used in indoor seating and tables |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture applicable to hard-surface table tops and structural stability | |
|---|---|---|
| GB 4706.1-2005 | Safety standard for household and similar electrical appliances covering integrated electric tea kettles | |
| GB/T 19001-2016 | Quality management system guideline for consistent furniture production and component sourcing | |
| GB 18584-2001 | Limit of harmful substances for wooden furniture applicable to any bonded trim or coating materials |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture applicable to hard-surface table tops and structural stability; 2. GB 4706.1-2005: Safety standard for household and similar electrical appliances covering integrated electric tea kettles; 3. GB/T 19001-2016: Quality management system guideline for consistent furniture production and component sourcing; 4. GB 18584-2001: Limit of harmful substances for wooden furniture applicable to any bonded trim or coating materials; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
