Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2540 x 1120 x 770 mm | |
|---|---|---|
| Tabletop thickness | 20 mm | |
| Under-table knee clearance height | 720 mm | |
| Left pedestal footprint | 600 x 400 mm | |
| Right pedestal footprint | 400 x 200 mm | |
| Long-side seating space per person | 630 mm | |
| End-side seating space per person | 1120 mm | |
| Tabletop overhang from base edge | 80 mm | |
| Individual bronze cylinder diameter (left base) | 120 mm | |
| Right support slab thickness | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static distributed load capacity | 250 kg | |
|---|---|---|
| Tabletop heat resistance (sealed finish) | 100 °C | |
| Structural warranty period | 3 years | |
| Supported seating capacity | 6 people | |
| Finish abrasion resistance (metal base) | 5000 cycles | |
| Net weight (complete table) | 200 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | Polished natural veined brown-grey marble, sealed stain-resistant surface | |
|---|---|---|
| Left base assembly | Cast iron with electroplated antique bronze finish, clustered vertical cylinders | |
| Right base assembly | Thick-gauge steel with electroplated antique bronze finish, single vertical slab | |
| Tabletop edge | Smooth eased polished edge, no sharp corners | |
| Base floor contact pads | Non-slip rubber pads to protect floor surfaces | |
| Assembly hardware | Zinc-plated steel M10 mounting bolts with lock washers | |
| Stone surface sealer | Penetrating matte sealer for stain and water resistance | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Fixed structure design | Non-extendable, non-adjustable rigid frame for stable tea and dining use | |
|---|---|---|
| Leveling adjustment | Threaded floor pads on base feet to compensate for uneven floors | |
| Surface utility | Smooth non-porous sealed surface suitable for hot tea service and dining ware | |
| Seating access | Open under-table space allows chair placement on all four sides | |
| Surface maintenance | Sealed finish allows wipe-clean care for spills and tea stains | |
| Load distribution | Dual pedestal design spreads weight evenly to prevent tabletop flex | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Luxury home dining room | Serves 6 people for formal family meals and tea gatherings, fits 3m+ wide dining spaces | |
|---|---|---|
| Private tea room or club lounge | Provides dedicated surface for formal tea service for small groups | |
| Upscale boutique hotel dining suite | Coordinates with matching New Chinese style armchairs for guest reception areas | |
| Open-plan living area dining zone | Low-profile asymmetrical base creates visual interest without blocking sight lines | |
| Executive reception lounge | Functions as a meeting table for small casual discussions and light refreshments |
EU Market Access Requirements* EN Standards
| Furniture surface durability | EN 15185:2011 | |
|---|---|---|
| Furniture stability testing | EN 1730:2012 | |
| Furniture mechanical safety | EN 12521:2015 |
Standards applicable to China-market projects
| Tabletop stone safety | GB 6566 | |
|---|---|---|
| Furniture structural safety | GB/T 3324 | |
| Metal coating durability | GB/T 1993 | |
| Formaldehyde emission | GB 18584 |
This product must meet the following technical requirements: 1. Tabletop stone safety: GB 6566; 2. Furniture structural safety: GB/T 3324; 3. Metal coating durability: GB/T 1993; 4. Formaldehyde emission: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
