| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1300 x 700 x 550 mm | |
|---|---|---|
| Table top thickness | 12 mm | |
| Embedded tea tray dimensions | 600 x 400 mm | |
| Left cabinet dimensions | 450 x 700 x 538 mm | |
| Right angled metal leg section | 50 x 30 mm rectangular tube | |
| Vertical slat grille spacing | 40 mm between bars | |
| Lower open shelf clearance below top | 220 mm | |
| Lower shelf depth | 400 mm | |
| Right-side leg setback from edge | 80 mm | |
| Knee clearance height under right top | 500 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total product weight | 60 kg | |
|---|---|---|
| Distributed static table top load | 100 kg | |
| Sintered stone top heat resistance | 1200 °C | |
| Sintered stone surface abrasion resistance | Grade 3, 6000 revolutions | |
| Lower open shelf static load | 30 kg | |
| Recommended number of users | 4 people | |
| Product warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table top | 12mm polished grey sintered stone, marble vein finish, scratch-resistant | |
|---|---|---|
| Embedded tea tray | Black food-grade melamine, recessed flush with tabletop, with drainage outlet | |
| Left support cabinet | E0 grade engineered wood, dark grey matte finish, with internal closed storage | |
| Cabinet accent panel | Black sintered stone with white marble veins, set into cabinet front | |
| Front vertical slats | 1.2mm thick matte black carbon steel bars, evenly spaced grille design | |
| Right support leg | Matte black carbon steel rectangular tube, angled for structural stability | |
| Lower open shelf | 15mm thick dark grey engineered wood, fixed between cabinet and leg | |
| Frame connectors | Zinc-plated steel cam lock screws and angle brackets, 16 pieces per unit | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Integrated tea tray drainage | Recessed tray connects to hidden plastic wastewater pipe for continuous drainage | |
|---|---|---|
| Bottom-feed kettle compatibility | Pre-drilled cable and hose channel in left cabinet for electric water boiler | |
| Closed left cabinet storage | Internal adjustable shelf stores tea canisters, kettles and cleaning supplies | |
| Open lower shelf storage | Full-width open shelf holds tea cups, tea pets and serving trays for easy access | |
| Heat-resistant work surface | Sintered stone top supports direct placement of boiling kettles without heat mats | |
| Asymmetrical load distribution | Left cabinet and right angled leg transfer load evenly to prevent tabletop warping | |
| Non-marking foot pads | Adjustable plastic foot pads on cabinet base and leg level table on uneven floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Living room casual tea area | Placed in front of sofa for daily tea drinking and guest reception | |
|---|---|---|
| Office reception area | Installed in meeting lounge areas for client tea service | |
| Home tea room | Used in dedicated small tea rooms for personal or small group tea sessions | |
| Balcony leisure space | Positioned on covered balconies for relaxed afternoon tea use | |
| Matching configuration recommendation | Pair with 4 low-profile 420mm seat height tea stools for complete seating |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic tables, applicable to structural testing | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for surface resistance to mechanical damage |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to cabinet structure | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for wood furniture | |
| GB/T 4897.3-2003 | Particleboard specification for furniture use, applicable to engineered wood components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to cabinet structure; 2. GB 18584-2001: Indoor decoration material formaldehyde emission limit for wood furniture; 3. GB/T 4897.3-2003: Particleboard specification for furniture use, applicable to engineered wood components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
