Automatic mm / inch conversion · Core engineering specifications
| Overall table dimensions | 1800 x 800 x 750 mm | |
|---|---|---|
| Table top thickness | 80 mm | |
| Host chair overall dimensions | 620 x 550 x 900 mm | |
| Guest chair overall dimensions | 580 x 500 x 780 mm | |
| Chair seat height | 460 mm | |
| Embedded tea tray dimensions | 1200 x 400 mm | |
| Electric tea stove cutout dimensions | 380 x 480 mm | |
| Lower slatted stretcher height from floor | 220 mm | |
| Leg spacing at floor (long side) | 1600 mm | |
| Under-table knee clearance height | 620 mm | |
| Clearance between table frame and opposite seat edge | 400 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set static load capacity | 300 kg | |
|---|---|---|
| Table top stone surface heat resistance | 120 °C | |
| Wood frame moisture content after drying | 12% | |
| Embedded electric tea stove power rating | 2000 W | |
| Tea tray drainage flow rate | 1.2 L/min | |
| Surface scratch resistance (wood finish) | 2H pencil hardness | |
| Set suitable user count | 5 people | |
| Warranty period | 3 years | |
| Available finish color options | 4 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table frame and legs | Solid hardwood with walnut-tone water-based paint finish | |
|---|---|---|
| Recessed central tea tray | Polished black Wujin natural stone, 20mm thickness | |
| Table top non-tea work zones | Light beige sintered stone slab, 12mm thickness | |
| Lower slatted stretcher | Solid wood vertical slats with horizontal cross beams | |
| Chair frames | Solid hardwood matching table finish, curved back rails | |
| Chair seat upholstery | Black matte PU leather over high-density foam | |
| Embedded electric tea stove base | Heat-resistant tempered glass top with stainless steel kettle | |
| Hardware fasteners | Zinc-plated steel connecting brackets with anti-rust coating | |
| Drainage components for tea tray | Food-grade silicone hose with removable filter basket | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Integrated tea brewing station | Embedded electric kettle with automatic water refill and boil function | |
|---|---|---|
| Recessed tea tray drainage | Built-in sloped channel directing waste water to external collection bucket | |
| Modular surface zoning | Separate dedicated zones for tea boiling, tea serving, and accessory placement | |
| Lower slatted footrest | Horizontal slat structure at foot height supporting foot placement during long sessions | |
| Inverted trapezoid leg structure | Splayed leg design widening at floor contact point to prevent tipping | |
| Knock-down assembly design | Flat-pack table and chair components with pre-drilled connection points | |
| Stain-resistant top surfaces | Non-porous stone and sealed wood surfaces wipe clean of tea stains | |
| Symmetric seating layout | 1 host seat at short end, two guest seats per long side for 5-person service | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Office executive reception room | Suitable for 5-person business tea reception and formal client meetings | |
|---|---|---|
| Private home tea room | Designed for daily family tea tasting and small casual gatherings | |
| Commercial tea house private booth | Appropriate for paid tea service booth seating for small groups | |
| Hotel lounge hospitality area | Fits luxury lounge areas for serving welcome tea to guests | |
| Conference side break area | Positioned adjacent to meeting rooms for post-meeting informal discussion | |
| Studio or cultural space | Suitable for cultural activity spaces hosting calligraphy or tea ceremony events | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
| GB 18580-2017 | Applicable formaldehyde emission limit ≤0.124mg/m³ for wood-based panel components | |
|---|---|---|
| GB/T 3324-2017 | Applicable general technical requirements for wooden furniture dimensions and stability | |
| GB 4706.1-2005 | Applicable safety standard for embedded household electric tea stove appliances |
This product must meet the following technical requirements: 1. GB 18580-2017: Applicable formaldehyde emission limit ≤0.124mg/m³ for wood-based panel components; 2. GB/T 3324-2017: Applicable general technical requirements for wooden furniture dimensions and stability; 3. GB 4706.1-2005: Applicable safety standard for embedded household electric tea stove appliances; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
