Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 900 × 760 mm | |
|---|---|---|
| Sintered stone worktop thickness | 40 mm | |
| Cabinet side panel thickness | 18 mm | |
| PUR edge band thickness | 2 mm | |
| Central knee clearance width | 1200 mm | |
| Knee clearance height under worktop | 680 mm | |
| Knee clearance depth under worktop | 450 mm | |
| Pedestal width per side | 600 mm | |
| Rear cable channel width | 80 mm | |
| Cable grommet diameter | 60 mm | |
| Recessed handle length per pedestal | 120 mm | |
| Corner radius on worktop edges | 10 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight (per unit) | 195 kg | |
|---|---|---|
| Worktop static uniform load | 200 kg | |
| Per-drawer dynamic load rating | 45 kg | |
| Drawer slide cycle rating | 100000 cycles | |
| Door hinge cycle rating | 100000 cycles | |
| Under-desk cable tray load capacity | 10 kg | |
| Sintered stone surface scratch resistance | 6 Mohs | |
| PVD gold hardware corrosion resistance | 48 hours neutral salt spray | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop surface | Polished light gray sintered stone | |
|---|---|---|
| Pedestal cabinet panels | ENF-grade low-emission particleboard | |
| Internal support frame | 1.5mm thick cold-rolled steel | |
| Pedestal inner reinforcement | Solid multilayer wood core | |
| Hardware accents | Zinc alloy with PVD titanium gold finish | |
| Drawer slides | Three-section full-extension cold-rolled steel | |
| Door hinges | Cold-rolled steel with nickel plating | |
| Edge banding | 2mm thick ABS | |
| Cable channel trim | Brushed aluminum alloy | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Dual pedestal storage | Each side pedestal includes 2 drawers and 1 door compartment | |
|---|---|---|
| Integrated cable management | Rear recessed channel with grommets routes power/data cables | |
| Soft-close drawer operation | Drawers close silently with automatic damping | |
| Soft-close door operation | Cabinet doors close gently with adjustable hinge tension | |
| Fixed ergonomic work height | 760mm work surface aligned with standard office chairs | |
| Rounded edge safety design | CNC polished 10mm radius corners and edges | |
| Optional host compartment | Left pedestal includes ventilated open bay for computer tower | |
| Flush recessed handle design | Vertical gold pulls sit flush with pedestal front | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Fits 30sqm+ independent executive spaces for 1 primary user | |
|---|---|---|
| High-end home office | Suitable for luxury residential study spaces with matching seating | |
| Boutique corporate reception area | Pairs with visitor chairs for small in-room meetings at the desk | |
| Recommended seating configuration | 1 executive armchair + 2 visitor armchairs | |
| Recommended companion accessories | Desk mat, monitor arm, cable organizer, desk lamp | |
| Floor surface requirement | Compatible with level low-pile carpet or polished tile floors |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Office furniture strength and stability | EN 527:2002 | |
|---|---|---|
| Formaldehyde emission for panels | EN 13986:2004 | |
| Surface abrasion resistance | EN 15185:2011 |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| Office desk performance standard | ANSI/BIFMA X2021 | |
|---|---|---|
| Storage unit performance standard | ANSI/BIFMA X2019 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Desk dimensional and safety standard | GB/T 3326 | |
|---|---|---|
| Wood-based panel emission standard | GB 18580 | |
| Hardware durability standard | GB/T 10357.5 | |
| Surface coating adhesion standard | GB/T 4893.4 |
This product must meet the following technical requirements: 1. Desk dimensional and safety standard: GB/T 3326; 2. Wood-based panel emission standard: GB 18580; 3. Hardware durability standard: GB/T 10357.5; 4. Surface coating adhesion standard: GB/T 4893.4; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
