Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1500 x 800 x 580 mm | |
|---|---|---|
| Knee clearance width between pedestals | 700 mm | |
| Knee clearance height under tabletop | 520 mm | |
| Integrated brew station cutout size | 370 x 520 mm | |
| Tea tray serving area cutout size | 370 x 200 mm | |
| Tabletop slab thickness | 20 mm | |
| Pedestal base footprint (each) | 350 x 800 mm | |
| Table edge overhang beyond pedestals | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 150 kg | |
|---|---|---|
| Kettle heating power | 1500 W | |
| Sterilizer pot heating power | 700 W | |
| Kettle boil time for full capacity | 3 minutes | |
| Net product weight | 95 kg | |
| Recommended seating capacity | 4 users | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop surface | White veined sintered stone/marble composite slab | |
|---|---|---|
| Pedestal base paneling | Walnut wood veneer over MDF core | |
| Base trim and edging | Matte black powder-coated steel | |
| Electric kettle body | 304 food-grade stainless steel | |
| Sterilizer pot body | 304 food-grade stainless steel | |
| Serving tea tray insert | Black wear-resistant melamine composite | |
| Internal support framework | 1.5mm thick square steel tube | |
| Base foot glides | Adjustable nylon floor glides | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Integrated electric kettle function | Auto-fill bottom water supply, 1.2L capacity, 100C boil mode | |
|---|---|---|
| Sterilizer pot function | Boiling steam sterilization for teacups and teaware, 0.8L capacity | |
| Temperature control function | Three preset heat settings for green, oolong, and black tea service | |
| Tea tray drainage function | Concealed gravity drain line connection for waste water collection | |
| Leveling adjustment function | 20mm height adjustment via nylon base glides for uneven carpeted floors | |
| Tabletop surface performance | Heat-resistant to 180C, scratch-resistant, stain-resistant for tea service use | |
| Concealed wiring function | Internal cable channel for power cord routing to wall outlets | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Office reception lounge | Suitable for guest tea service in executive reception and waiting areas | |
|---|---|---|
| Small meeting room | Used for informal discussion and tea service for 4-person meeting groups | |
| Executive office private space | Placed beside lounge seating for private guest entertainment | |
| Open office breakout area | Provides casual refreshment point for staff and visitor use |
EU Market Access Requirements* EN Standards
| Furniture mechanical safety | EN 12521:2015 | |
|---|---|---|
| Stone surface durability | EN 14617:2016 | |
| Electrical appliance safety | EN 60335:2012 |
Standards applicable to China-market projects
| Tabletop stone panel safety | GB 6566 | |
|---|---|---|
| Furniture structural safety | GB/T 3324 | |
| Electrical component safety | GB 4706.1 | |
| Furniture formaldehyde emission | GB 18584 |
This product must meet the following technical requirements: 1. Tabletop stone panel safety: GB 6566; 2. Furniture structural safety: GB/T 3324; 3. Electrical component safety: GB 4706.1; 4. Furniture formaldehyde emission: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
