Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2600 x 800 x 750 mm | |
|---|---|---|
| Tabletop thickness | 12 mm | |
| Embedded appliance cutout | 370 x 230 mm | |
| Tea tray placement area | 800 x 350 mm | |
| Drawer front slat height | 30 mm | |
| Geometric inset panel height | 550 mm | |
| Base overhang from table edge | 50 mm | |
| Adjustable foot height | 15 mm | |
| Internal drawer depth | 650 mm | |
| Table edge profile radius | 5 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 150 kg | |
|---|---|---|
| Kettle boiling capacity | 1.2 L | |
| Sterilizer pot capacity | 0.8 L | |
| Product net weight | 220 kg | |
| Tabletop heat resistance | 180 °C | |
| Tabletop abrasion resistance | 2000 cycles | |
| Recommended user capacity | 6 people | |
| Warranty period | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | 12mm white sintered stone with marble vein finish | |
|---|---|---|
| Base frame | E0-grade dark walnut engineered wood | |
| Front accent insets | Matching white sintered stone | |
| Storage drawer internals | Melamine-lined engineered wood | |
| Tea boiler body | Food-grade 304 stainless steel | |
| Tea tray mat | Black waterproof non-slip silicone | |
| Leveling feet | Nylon with non-slip rubber base | |
| Drawer hardware | Cold-rolled steel silent slides | |
| Water tubing | Food-grade silicone | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Integrated auto water supply | Built-in pump draws water from stored jug to kettle automatically | |
|---|---|---|
| Automatic boil and shutoff | Kettle boils water in 3 minutes, cuts power at 100°C to prevent dry burn | |
| Teaware sterilization | Dual-basin sterilizer pot uses boiling water to sanitize teacups between uses | |
| Concealed drainage system | Gravity drain line removes excess tea wastewater to hidden collection tank | |
| Two-side slat-front storage | Six horizontal pull drawers on each side store tea, cups and supplies | |
| Adjustable leveling feet | 15mm height adjustment on each base corner compensates for uneven floors | |
| Heat-resistant table surface | Sintered stone top withstands direct placement of hot kettles without scorching | |
| Waterproof edge sealing | Sealed tabletop joints prevent water seepage into base frame | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Executive office reception area | Serves guests during business meetings with convenient tea preparation | |
|---|---|---|
| Corporate lounge and waiting zone | Provides self-serve tea service for waiting visitors with tidy concealed storage | |
| Private clubhouse tea room | Supports formal kung fu tea service for member gatherings, durable for daily use | |
| High-end residential living room | Functions as a premium coffee table with integrated tea making capability | |
| Recommended matching seating | Low-profile armless tea chairs with 450mm seat height |
EU Market Access Requirements* EN Standards
| EN 13722:2004 | Furniture strength and durability for tables, applicable for structural load verification | |
|---|---|---|
| EN 12546-1:2000 | Food contact materials, applicable for water contact tea appliance components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for base frame structural integrity | |
|---|---|---|
| GB 4806.9-2016 | Food contact metal material safety, applicable for stainless steel tea boilers and pots | |
| GB/T 4100-2015 | Ceramic tile standards, applicable for sintered stone tabletop performance requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for base frame structural integrity; 2. GB 4806.9-2016: Food contact metal material safety, applicable for stainless steel tea boilers and pots; 3. GB/T 4100-2015: Ceramic tile standards, applicable for sintered stone tabletop performance requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
