| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 800 x 750 mm | |
|---|---|---|
| Tabletop thickness | 100 mm | |
| Pedestal base width | 400 mm | |
| Pedestal base height | 700 mm | |
| Embedded tea module dimensions | 600 x 400 mm | |
| Floor clearance under table edge | 50 mm | |
| Decorative slat panel width on left base | 200 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 300 kg | |
|---|---|---|
| Integrated water boiler tank capacity | 3 L | |
| Maximum supported user weight per chair | 150 kg | |
| Tea module heating power | 1200 W | |
| Surface high-temperature resistance near boiler | 180 °C | |
| Recommended seating capacity | 6 persons | |
| Seating capacity clearance per seat | 650 mm | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | High-density MDF with high-gloss black UV lacquer finish | |
|---|---|---|
| Alternative tabletop option note | Sintered stone slab with polished black finish | |
| Pedestal base construction | Solid engineered wood core with matching high-gloss black paint | |
| Decorative slat inlay | Brushed stainless steel vertical trim strips | |
| Tea station tray | Food-grade 304 stainless steel recessed drainage tray | |
| Control panel | Touch-sensitive tempered glass control panel | |
| Matching chair seat/back upholstery | Matte light beige performance fabric, 40mm high-density foam padding | |
| Matching chair frame | Solid ash wood with matte black stain finish | |
| Foot pads | Non-slip adjustable nylon foot pads | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Integrated water boiling | One-touch electric water heating with automatic temperature control | |
|---|---|---|
| Automatic water feed | Bottom-fill water supply connection with auto shutoff when full | |
| Hidden drainage system | Concealed drain pipe connection for waste water removal from tea tray | |
| Dual pedestal support | Dual end block bases eliminate cross-bracing for full perimeter legroom | |
| Easy-clean surface | Non-porous high-gloss finish resists tea stains and wipes clean with damp cloth | |
| Leveling adjustment | Adjustable foot pads compensate for uneven floor surfaces up to 10mm | |
| Modular tea component access | Removable tea tray allows easy cleaning and maintenance of boiler components | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Office reception lounge | Suitable for executive reception areas to serve guests during tea meetings | |
|---|---|---|
| High-end residential living room | Fits luxury open-plan living spaces for home tea service and entertaining | |
| Private club lounge | Appropriate for upscale lounge and club spaces for casual guest seating | |
| Executive breakout area | Works in office breakout zones for informal team gatherings over tea | |
| Recommended paired seating | 6 matching curved light-fabric lounge armchairs for full perimeter seating | |
| Required installation access | Position within 1m of water supply and drain connection for fully functional tea module |
EU Market Access Requirements* EN Standards
| Furniture surface scratch resistance | EN 15185:2011 Determination of scratch resistance for furniture surfaces | |
|---|---|---|
| Furniture stability for freestanding tables | EN 1730:2012 Test methods for tables - Determination of stability, strength and durability |
Standards applicable to China-market projects
| Tabletop formaldehyde emission | GB 18580E1 grade ≤0.124mg/m³ | |
|---|---|---|
| Furniture structural safety for hard tables | GB/T 3324General technical requirements for wooden furniture | |
| Electrical safety for integrated appliance | GB 4706.1Safety of household and similar electrical appliances |
This product must meet the following technical requirements: 1. Tabletop formaldehyde emission: GB 18580E1 grade ≤0.124mg/m³; 2. Furniture structural safety for hard tables: GB/T 3324General technical requirements for wooden furniture; 3. Electrical safety for integrated appliance: GB 4706.1Safety of household and similar electrical appliances; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
