Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2200 × 800 × 750 mm | |
|---|---|---|
| Tabletop thickness | 80 mm | |
| Integrated marble tea station dimensions | 620 x 460 mm | |
| Transparent acrylic pedestal thickness | 30 mm | |
| Clear under-table knee clearance height | 670 mm | |
| Long-side seating legroom depth | 300 mm | |
| Matching guest chair seat height | 450 mm | |
| Acrylic pedestal width (table depth axis) | 400 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total table static load capacity | 300 kg | |
|---|---|---|
| Maximum seated user capacity | 4 people | |
| Stone tea station surface heat resistance | 180 °C | |
| Stone surface scratch resistance (Martindale) | 2000 cycles | |
| Acrylic support service life | 8 years | |
| Integrated electric boiler power rating | 1500 W | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main tabletop substrate | 20mm thick multilayer engineered wood, E0 emission grade | |
|---|---|---|
| Tabletop surface finish | Walnut wood veneer with matte polyurethane sealant | |
| Tea station and left pedestal | Black natural marble with white veining, anti-penetration seal | |
| Right support pedestal | 30mm thick high-transparency clear cast acrylic | |
| Integrated tea tray insert | Food-grade black slate, routed drain channel | |
| Frame joinery | Mortise and tenon wood connections with reinforced steel hardware | |
| Undertable storage compartment | Laminated engineered wood panel, hidden access for water buckets | |
| Edge treatment | 45-degree beveled polished wood edges, smooth radius finish | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated water supply system | One-touch auto-fill function for electric kettle, connected to hidden water reservoir | |
|---|---|---|
| Built-in drainage system | Gravity-fed drain line connected to hidden waste water bucket under table | |
| Hidden storage compartment | Enclosed under-pedestal space holds 19L clean and waste water buckets | |
| Boiling temperature control | 3 preset temperature modes for different tea types, boil-dry protection | |
| Surface cleanability | Sealed marble and wood surfaces wipe clean with damp cloth, resist tea stain penetration | |
| Seating configuration | Supports 4 upholstered guest chairs across long sides, optional 1 host chair at tea station end | |
| Leveling adjustment | Adjustable foot pads on both pedestals to compensate for uneven flooring | |
| Black marble block pedestal dimensions | 450 x 450 x 670 mm | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office reception tea room | Fits executive reception areas for 4-person business tea meetings | |
|---|---|---|
| Private home tea lounge | Suitable for residential living rooms or dedicated tea spaces for home entertaining | |
| Teahouse private booth | Works for high-end commercial teahouse private rooms for guest service | |
| Club lounge seating area | Applicable for private club or co-working lounge casual meeting zones | |
| Recommended matching setup | Pair with 4 upholstered wooden armchairs and complementary display shelving |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Furniture mechanical safety standard | EN 12521:2015 | |
|---|---|---|
| Formaldehyde emission standard | EN 13986:2004 | |
| Surface abrasion resistance standard | EN 15186:2012 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Wood-based panel emission standard | GB/T 18580 | |
|---|---|---|
| Furniture surface durability standard | GB/T 4893.4 | |
| Furniture structural strength standard | GB/T 10357.1 | |
| Household electrical appliance safety | GB 4706.1 |
This product must meet the following technical requirements: 1. Wood-based panel emission standard: GB/T 18580; 2. Furniture surface durability standard: GB/T 4893.4; 3. Furniture structural strength standard: GB/T 10357.1; 4. Household electrical appliance safety: GB 4706.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
