Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1600 x 900 x 550 mm | |
|---|---|---|
| Tabletop thickness | 12 mm | |
| Embedded electric boiler cutout size | 370 x 200 mm | |
| Embedded tea tray cutout size | 600 x 200 mm | |
| Base cabinet height | 538 mm | |
| Frame tube wall thickness | 1.5 mm | |
| Cabinet panel thickness | 18 mm | |
| Side cabinet door width | 650 mm | |
| Central slatted storage section width | 300 mm | |
| Tabletop overhang past base | 20 mm | |
| Kettle base recess depth | 12 mm | |
| Tea tray recess depth | 10 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Table net weight | 95 kg | |
|---|---|---|
| Distributed tabletop static load | 150 kg | |
| Kettle maximum boiling power | 1500 W | |
| Sterilizer pot power | 700 W | |
| Maximum suitable simultaneous users | 5 people | |
| Water boil time | 4 minutes | |
| Surface heat resistance | 1200 °C | |
| Surface abrasion resistance | 6000 revolutions | |
| Door hinge cycle rating | 50000 open/close cycles | |
| Bed Static Load Reference | 400 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | 12mm polished white sintered stone with marble veining, heat and stain resistant | |
|---|---|---|
| Perimeter support frame | 1.5mm thick matte black powder-coated square steel tubing | |
| Cabinet door and side panels | 18mm fluted wood-grain engineered wood panels, matte finish | |
| Central slatted dividers | Black matte finish vertical engineered wood slats, open pass-through design | |
| Embedded boiler/sterilizer pots | Food-contact 304 stainless steel construction | |
| Electric kettle control base | Heat-resistant food-contact plastic with integrated auto-fill water pump | |
| Embedded tea tray insert | Black matte solid surface panel with recessed drainage channel | |
| Internal cabinet storage shelf | 15mm thick engineered wood, height adjustable for water bucket storage | |
| Door hinges and hardware | Cold-rolled steel with matte black finish, soft-close mechanism | |
| Adjustable foot glides | 10mm diameter nylon, 15mm height adjustment range for level installation | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner |
Adjustment / rotation / tilt / mobility / storage features
| Dual-station embedded tea service | Left inset houses boiler and sterilizer, right inset holds slotted tea tray with drainage | |
|---|---|---|
| Auto-fill water supply system | Bottom-feed pump draws from concealed internal water bucket for one-touch refill | |
| Enclosed dual-side storage | Left and right hinged cabinet doors store tea accessories, supplies and cleaning tools | |
| Central utility storage bay | Open vertical slat section conceals water supply bucket and waste water bin for tidy operation | |
| Boiler safety protection | Dry-boil automatic shutoff, boil-dry protection and overheat cutout for unattended use | |
| Temperature preset controls | Three preset temperatures (85°C, 95°C, 100°C) for different tea varieties | |
| Integrated drainage system | Hidden drain line connects tea tray to internal waste water container, no external plumbing required | |
| Smooth edge profile | Rounded polished tabletop edges eliminate sharp corners for safe reception use | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Main table shipping carton dimensions | 1700 x 1000 x 700 mm | |
|---|---|---|
| Total shipping gross weight | 112 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Office reception areas | Serves waiting guests during business meetings, accommodates 5 visitors at once | |
|---|---|---|
| Home living room lounge areas | Low height pairs with standard sofas for casual tea service during gatherings | |
| Private study or tea rooms | Self-contained water and drainage system eliminates plumbing modifications for dedicated tea spaces | |
| VIP lounge and club spaces | Neat concealed storage and polished finish maintains tidy professional appearance for high-end settings | |
| Small apartment balcony spaces | Compact 1.6m footprint fits narrow balconies for casual personal tea preparation |
EU Market Access Requirements* EN Standards
| Furniture stability requirements | EN 15372:2016 Furniture – Strength, durability and safety for non-domestic storage furniture | |
|---|---|---|
| Sintered stone surface performance | EN 14617:2016 Agglomerated stone – Test methods for flexural strength | |
| Electrical safety for appliances | EN 60335:2012 Safety of household and similar electrical appliances |
Standards applicable to China-market projects
| Furniture structural safety | GB/T 3324General technical requirements for wooden furniture | |
|---|---|---|
| Sintered stone surface performance | GB/T 3810.1Test methods for ceramic tiles | |
| Electric tea appliance safety | GB 4706.1Safety of household and similar electrical appliances | |
| Formaldehyde emission limits | GB 18580Formaldehyde emission for wood-based panels | |
| Furniture hardware durability | GB/T 17657Test methods for wood-based furniture surfaces |
This product must meet the following technical requirements: 1. Furniture structural safety: GB/T 3324General technical requirements for wooden furniture; 2. Sintered stone surface performance: GB/T 3810.1Test methods for ceramic tiles; 3. Electric tea appliance safety: GB 4706.1Safety of household and similar electrical appliances; 4. Formaldehyde emission limits: GB 18580Formaldehyde emission for wood-based panels; 5. Furniture hardware durability: GB/T 17657Test methods for wood-based furniture surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
