New Chinese Style Mixed Pedestal Tea Ceremony Meeting Table with Integrated Drainage Tea Tray (model TC-NC-2400STW) is listed under Tea station table. Dimensions: 2400 × 900 × 750 mm. Materials: North American black walnut solid wood with clear water-based polyurethane finish. Load capacity: 200 kg. Product Features: new,Chinese,style,fixed,pedestal,base,integrated,tea,system,mixed,material,construction. This page consolidates 6 groups of specifications and GB / EN standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | JUESHANGDA | Model | TC-NC-2400STW |
| Overall dimensions (W × D × H) | 2400 × 900 × 750 mm | tabletop thickness | 80 mm |
| embedded tea tray size | 900 x 450 mm | knee clearance under table | 670 mm |
| edge radius on tabletop | 5 mm | left sintered stone pedestal size | 600 x 450 x 700 mm |
| right solid wood pedestal size | 400 x 350 x 700 mm | boiler station indent size | 400 x 300 mm |
| floor clearance under pedestal | 0 mm | Finished Top Thickness | 45 mm |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | Leg / Support Section | 80 mm main section with 2 mm metal wall |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm | table net weight | 150 kg |
| tabletop uniform static load | 200 kg | tea tray drainage flow rate | 2 L/min |
| seating capacity | 6 people | design service life | 10 years |
| surface water resistance rating | Level 4 | surface abrasion resistance | 2000 cycles |
| seating capacity per side | 2 chairs on long sides, 1 chair on each short end | Top Static Load Reference | 150 kg uniformly distributed |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | tabletop slab | North American black walnut solid wood with clear water-based polyurethane finish |
| left support pedestal | Polished natural marble/sintered stone slab with sealed textured surface | right support pedestal | Solid laminated wood block with matching walnut veneer and matte finish |
| embedded tea tray | Black polished natural stone with sloped drainage channel and brass drain fitting | kettle station platform | Textured sintered stone inset with heat-resistant surface |
| edge treatment | Hand-sanded rounded edges with sealed finish, no sharp corners | pedestal connection hardware | Zinc-plated steel corner brackets with M10 mounting bolts |
| floor protection pads | 8 mm thick non-slip rubber pads under each pedestal base | Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
| Edge Band Thickness | 2 mm | Metal Frame Wall Thickness | 2 mm cold-rolled steel |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | integrated tea drainage system | Sloped tea tray connects to hidden waste water pipe routed to under-table bucket |
| integrated boiler mounting | Recessed left station accommodates embedded electric glass kettle with concealed power cord routing | pedestal structural design | Dual asymmetric pedestal bases eliminate crossbars, 360-degree unobstructed legroom for seated users |
| fixed height design | 750 mm working height optimized for standard 450 mm seat height dining/tea chairs | surface maintenance design | Smooth sealed non-porous surfaces allow wipe-clean of tea stains and spills without waxing |
| multi-use adaptability | Table supports formal tea ceremony, small business meetings, and casual dining for six users | concealed cable routing | Hidden channel under tabletop routes power cord for electric kettle without surface clutter |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
| Reference Package Count | 1 set / 2 cartons | Reference Assembly Time | 40 minutes per set |
| Reference Package Dimensions | 2100× 1100× 300 mm | Reference Packaged Gross Weight | 90 kg/set in 2 cartons |
| Reference Packaging Volume | 0.55 m³/set | private residential tea room | Designed for home tea ceremony, guest reception and family casual dining |
| office executive reception area | Suitable for small business meetings and client reception in corporate settings | tea house private booth | Meets commercial durability requirements for frequent daily tea service use |
| clubhouse lounge space | Fits senior living and private club social activity spaces | recommended matching seating | 1 host armchair plus 5 guest armchairs with linen upholstery |
| floor type compatibility | Suitable for tile, polished concrete, solid wood and engineered wood flooring | — | — |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 900 × 750 mm | |
|---|---|---|
| tabletop thickness | 80 mm | |
| embedded tea tray size | 900 x 450 mm | |
| knee clearance under table | 670 mm | |
| edge radius on tabletop | 5 mm | |
| left sintered stone pedestal size | 600 x 450 x 700 mm | |
| right solid wood pedestal size | 400 x 350 x 700 mm | |
| boiler station indent size | 400 x 300 mm | |
| floor clearance under pedestal | 0 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| table net weight | 150 kg | |
|---|---|---|
| tabletop uniform static load | 200 kg | |
| tea tray drainage flow rate | 2 L/min | |
| seating capacity | 6 people | |
| design service life | 10 years | |
| surface water resistance rating | Level 4 | |
| surface abrasion resistance | 2000 cycles | |
| seating capacity per side | 2 chairs on long sides, 1 chair on each short end | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| tabletop slab | North American black walnut solid wood with clear water-based polyurethane finish | |
|---|---|---|
| left support pedestal | Polished natural marble/sintered stone slab with sealed textured surface | |
| right support pedestal | Solid laminated wood block with matching walnut veneer and matte finish | |
| embedded tea tray | Black polished natural stone with sloped drainage channel and brass drain fitting | |
| kettle station platform | Textured sintered stone inset with heat-resistant surface | |
| edge treatment | Hand-sanded rounded edges with sealed finish, no sharp corners | |
| pedestal connection hardware | Zinc-plated steel corner brackets with M10 mounting bolts | |
| floor protection pads | 8 mm thick non-slip rubber pads under each pedestal base | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| integrated tea drainage system | Sloped tea tray connects to hidden waste water pipe routed to under-table bucket | |
|---|---|---|
| integrated boiler mounting | Recessed left station accommodates embedded electric glass kettle with concealed power cord routing | |
| pedestal structural design | Dual asymmetric pedestal bases eliminate crossbars, 360-degree unobstructed legroom for seated users | |
| fixed height design | 750 mm working height optimized for standard 450 mm seat height dining/tea chairs | |
| surface maintenance design | Smooth sealed non-porous surfaces allow wipe-clean of tea stains and spills without waxing | |
| multi-use adaptability | Table supports formal tea ceremony, small business meetings, and casual dining for six users | |
| concealed cable routing | Hidden channel under tabletop routes power cord for electric kettle without surface clutter | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| private residential tea room | Designed for home tea ceremony, guest reception and family casual dining | |
|---|---|---|
| office executive reception area | Suitable for small business meetings and client reception in corporate settings | |
| tea house private booth | Meets commercial durability requirements for frequent daily tea service use | |
| clubhouse lounge space | Fits senior living and private club social activity spaces | |
| recommended matching seating | 1 host armchair plus 5 guest armchairs with linen upholstery | |
| floor type compatibility | Suitable for tile, polished concrete, solid wood and engineered wood flooring |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Strength, durability and stability requirements for domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Test methods for surface resistance to cold liquids for furniture finishes |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements applicable to wooden general furniture strength and stability | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limit requirement for indoor wooden furniture finishes | |
| GB/T 4893.4-2013 | Surface abrasion resistance test method applicable to painted wood tabletops | |
| GB/T 4893.9-2013 | Surface cigarette burn resistance test applicable to heat-resistant tea service surfaces |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements applicable to wooden general furniture strength and stability; 2. GB 18584-2001: Formaldehyde emission limit requirement for indoor wooden furniture finishes; 3. GB/T 4893.4-2013: Surface abrasion resistance test method applicable to painted wood tabletops; 4. GB/T 4893.9-2013: Surface cigarette burn resistance test applicable to heat-resistant tea service surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
