Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 800 × 750 mm | |
|---|---|---|
| Integrated side water cabinet dimensions | 800 x 600 x 650 mm | |
| Sintered stone tabletop thickness | 20 mm | |
| Table leg cross-section dimension | 60 x 60 mm | |
| Side cabinet door height | 580 mm | |
| Recessed tea service tray area on tabletop | 600 x 200 mm | |
| Under-table knee clearance height | 680 mm | |
| Edge banding thickness for cabinet components | 1 mm | |
| Anti-tip connector mounting height | 600 mm from floor | |
| Side cabinet internal shelf height | 300 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop static load capacity | 200 kg | |
|---|---|---|
| Recommended seating capacity | 6 people (1 host + 5 guests) | |
| Total set net weight (table only, no chairs) | 180 kg | |
| Sintered stone surface Mohs hardness | 7 | |
| Sintered stone surface heat resistance | 1500 °C | |
| Hinge cycle rating for cabinet doors | 100000 open/close cycles | |
| Drawer slide load rating (if equipped) | 25 kg | |
| Structural frame warranty period | 5 years | |
| Hardware component warranty period | 1 year | |
| Shelf Distributed Load | 30 kg/shelf |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop surface | 20mm polished grey-white sintered stone with natural marble veining | |
|---|---|---|
| Side cabinet carcass | 18mm matte grey moisture-resistant engineered wood | |
| Cabinet back panel | 5mm thick engineered wood backing | |
| Structural table legs | Matte dark grey powder-coated square steel tubing | |
| Hardware trim and handles | Brushed gold plated zinc alloy | |
| Cabinet door hinges | Cold-rolled steel soft-close hinges | |
| Edge banding | 1mm thick grey PVC edge banding | |
| Leveling feet under cabinet | Nylon and steel adjustable leveling feet | |
| Tabletop underside support frame | 1.2mm thick steel cross bracing | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Embedded electric tea kettle station | Integrated glass kettle with automatic water feed and boiling function | |
|---|---|---|
| Hidden drainage system for tea service | Concealed drain line connecting tabletop tray area to waste water bucket | |
| Double-door closed storage cabinet | Two soft-closing doors with internal adjustable shelf for tea supplies | |
| Recessed tea ware display area | Sunken central section to hold tea cups and brewing tools securely | |
| Adjustable cabinet leveling feet | Threaded feet to adjust cabinet height and level on uneven carpet | |
| Anti-tip wall anchoring provision | Pre-drilled holes for wall anchor straps to prevent cabinet tipping | |
| Gold decorative trim accent | Brushed gold trim along cabinet top edge, base and handle plates | |
| Easy-clean non-porous tabletop | Non-porous sintered stone surface resists tea stains and water damage | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Office reception lounge area | Suitable for hosting client meetings and tea service in corporate reception spaces | |
|---|---|---|
| Private tea room or clubhouse | Ideal for dedicated tea ceremony spaces in high-end clubs or private residences | |
| Open-plan executive office | Functions as a dual-purpose meeting and tea service surface in executive suites | |
| Residential living or dining space | Fits modern luxury home interiors for daily tea drinking and family dining | |
| Balcony small leisure area (customized size) | Can be specified in smaller dimensions for residential balcony tea nooks | |
| Recommended matching seating | 1 host chair with orange upholstery + 5 guest chairs with beige fabric seats |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 14749:2016 Furniture - Domestic and kitchen storage units and worktops - Safety requirements | Applicable for storage cabinet structural safety and stability | |
|---|---|---|
| EN 13722:2004 Furniture - Test methods for the determination of strength and durability of storage furniture | Applicable for cabinet door and shelf load cycle testing | |
| EN 15186:2012 Furniture - Test methods for the assessment of surface resistance to dry heat | Applicable for sintered stone surface heat resistance testing |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable for engineered wood cabinet carcass quality inspection | |
|---|---|---|
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applicable for formaldehyde emission testing of engineered wood components | |
| GB/T 4897.3-2003 Particleboard - Part 3: Requirements for boards for interior fitments (including furniture) | Applicable for structural engineered wood panel performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable for engineered wood cabinet carcass quality inspection; 2. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applicable for formaldehyde emission testing of engineered wood components; 3. GB/T 4897.3-2003 Particleboard - Part 3: Requirements for boards for interior fitments (including furniture): Applicable for structural engineered wood panel performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
