Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 800 × 750 mm | |
|---|---|---|
| Main work surface length | 1800 mm | |
| Main work surface depth | 800 mm | |
| Side tea return surface length | 1000 mm | |
| Central seated knee clearance height | 620 mm | |
| Central seated knee clearance width | 800 mm | |
| Sintered stone top thickness | 12 mm | |
| Cabinet base side panel thickness | 18 mm | |
| Edge banding thickness | 2 mm | |
| Tea service storage compartment inner height | 450 mm | |
| Desk base gold trim strip width | 15 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static uniform load capacity | 150 kg | |
|---|---|---|
| Drawer slide load rating | 35 kg | |
| Hinge cycle rating | 80000 opening/closing cycles | |
| Desk net weight | 160 kg | |
| Recommended user weight capacity | 150 kg | |
| Surface abrasion resistance | 6 Mohs hardness | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main worktop | 12mm polished sintered stone, white marble-look finish | |
|---|---|---|
| Tea return worktop | 12mm matching sintered stone, matte polished finish | |
| Supporting pedestal bases | 18mm dark grey engineered wood panel, matte lacquer finish | |
| Decorative trim | Brushed gold-finish stainless steel strip, 15mm width | |
| Internal cabinet framing | 15mm multilayer plywood with anti-corrosion treatment | |
| Drawer slides | Cold-rolled steel 3-section ball-bearing slides, zinc-plated finish | |
| Cabinet hinges | Cold-rolled steel soft-close hydraulic hinges, nickel-plated | |
| Cable grommets | ABS plastic with brushed metal cover, 80mm diameter | |
| Base leveling feet | Nylon with adjustable steel screw, 10mm adjustment range | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated tea service station | Embedded boiling controls, drainage channel and hidden water bucket compartment | |
|---|---|---|
| Dual pedestal storage | Closed cabinet compartments on both left and right bases for document storage | |
| Central cable management | Dual 80mm cable grommets on main desk to route monitor and laptop cables | |
| Side return orientation | Installable on left or right side to fit office layout requirements | |
| Soft-close cabinet doors | Hydraulic hinges to prevent slamming and reduce noise during operation | |
| Adjustable leveling feet | 10mm vertical adjustment to compensate for uneven office floors | |
| Heat-resistant work surface | Sintered stone top supports hot tea kettles without surface damage | |
| Stain-resistant surface | Non-porous sintered stone resists tea and coffee stains for easy cleaning | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Fits 25sqm private offices for managerial work and guest tea reception | |
|---|---|---|
| Home office study | Suitable for high-end home studies for remote work and home tea hosting | |
| Small business reception room | Works in 30sqm reception areas for client meetings and tea service | |
| Managerial meeting space | Supports small 4person meetings with document work and tea service | |
| Open office supervisor station | Works as an upgraded supervisor station with integrated hospitality function |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Office furniture safety requirements | EN 527:2011 | |
|---|---|---|
| Office furniture dimensional requirements | EN 527:2016 | |
| Formaldehyde emission for wood panels | EN 13986:2004+A1:2015 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Office desk dimensional tolerance | GB/T 3326 | |
|---|---|---|
| Wood-based panel formaldehyde emission | GB 18580 | |
| Furniture surface coating durability | GB/T 4893.1 | |
| Office furniture structural stability | GB/T 10357.1 |
This product must meet the following technical requirements: 1. Office desk dimensional tolerance: GB/T 3326; 2. Wood-based panel formaldehyde emission: GB 18580; 3. Furniture surface coating durability: GB/T 4893.1; 4. Office furniture structural stability: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
