Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 700 × 450 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop static load capacity | 50 kg | |
|---|---|---|
| Net product weight | 28 kg | |
| Recommended maximum seated users for tea service | 4 | |
| Sintered stone surface scratch resistance (Mohs) | 6 | |
| Frame surface corrosion resistance | 48 hours neutral salt spray | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop | 12mm grey sintered stone with marble-look white veining, polished finish | |
|---|---|---|
| Edge banding | Stainless steel trims around tabletop perimeter, brushed metallic finish | |
| Support frame | Carbon steel rectangular tubing with matte black powder coating | |
| Lower shelf base panel | Black matte MDF backing panel | |
| Lower shelf surface | 8mm black tempered glass, high-gloss finish | |
| Foot pads | Non-slip PP plastic adjustable feet on each leg bottom | |
| Welded joints | Seam-welded steel joints ground smooth before powder coating | |
| Tabletop backing | High-density MDF substrate under sintered stone for reinforcement | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lower tier storage | Open fixed tempered glass shelf for tea accessories, books or decor | |
|---|---|---|
| Tea service layout | Flat heat-resistant tabletop supports electric tea boilers and tea trays | |
| Level adjustment | Adjustable plastic foot pads correct uneven floor surfaces up to 10mm | |
| Surface protection | Non-porous sintered stone top resists tea stains and hot water spills up to 180°C | |
| Frame stability | Box-style welded steel frame eliminates wobble during regular use | |
| Floor protection | Soft PP foot pads prevent scratches on tile, wood and stone flooring | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Living room placement | Positioned in front of sofas for casual drinks, snacks and tea service | |
|---|---|---|
| Office reception area use | Placed in reception lounges for serving guests during meetings | |
| Tea room dedicated use | Used as dedicated tea brewing table for home or small commercial tea spaces | |
| Small apartment dining alternative | Functions as low dining table for floor-seating arrangements in compact homes | |
| Balcony leisure use | Placed on covered balconies for casual drinks and light reading | |
| Recommended matching furniture | Pairs with 450 mm height floor cushions, low stools or deep-seated sofas |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Furniture safety general requirement | EN 12521:2015 | |
|---|---|---|
| Tempered glass safety | EN 12150:2015 | |
| Surface emission | EN 13986:2004+A1:2015 |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Sintered stone surface | GB/T 3810.3 | |
|---|---|---|
| Steel frame coating | GB/T 1993 | |
| Tempered glass shelf | GB 15763.2 | |
| Furniture structural stability | GB/T 10357.1 |
This product must meet the following technical requirements: 1. Sintered stone surface: GB/T 3810.3; 2. Steel frame coating: GB/T 1993; 3. Tempered glass shelf: GB 15763.2; 4. Furniture structural stability: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
