Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2200 x 900 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop uniform static load capacity | 150 kg | |
|---|---|---|
| Product net weight | 115 kg | |
| Recommended seating capacity | 6 persons | |
| Tabletop surface abrasion resistance | ≥4000 cycles | |
| Base vertical static load rating | 300 kg | |
| Surface heat resistance | 180 °C | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop panel | 12mm matte grey sintered stone | |
|---|---|---|
| Tea tray insert | Matte black phenolic composite | |
| Pedestal bases | 2mm thick cold-rolled steel | |
| Floor protection pads | 5mm thick non-slip rubber | |
| Tabletop understructure | 1.5mm thick steel support frame | |
| Surface finish (bases) | Textured matte powder coating | |
| Edge treatment | 45° chamfered polished stone edge | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Fixed height work surface | 750 mm standard seating height | |
|---|---|---|
| Integrated recessed tea service channel | Flush embedded black tray | |
| Dual pedestal open leg design | No central cross support obstruction | |
| Non-marring floor contact | Rubber padded base feet | |
| Stain resistant non-porous tabletop | Zero-seam sintered stone surface | |
| Leveling adjustment capacity | 10 mm adjustable foot pads | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| 20ft container loading quantity | 52 units | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Executive office tea lounge | Formal meeting and tea reception space for client visits | |
|---|---|---|
| Open plan office breakout area | Casual team discussion and refreshment zone for staff use | |
| Private tea room | Dedicated tea ceremony space for small group gatherings | |
| Modern residential dining area | Contemporary combined dining and tea service space for home use | |
| Hotel executive lounge | Guest reception and light refreshment area in premium hospitality settings |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
