Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 600 x 457 mm | |
|---|---|---|
| Tabletop thickness | 40 mm | |
| Lower shelf vertical clearance | 298 mm | |
| Leg frame tubular section size | 30 x 30 mm | |
| Frame wall thickness | 1.5 mm | |
| Lower shelf usable depth | 540 mm | |
| Lower shelf usable width | 1140 mm | |
| Floor clearance under lower shelf | 50 mm | |
| Adjustable foot pad height adjustment range | 10 mm | |
| Tabletop surface usable area | 0.72 m2 | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total table static distributed load capacity | 136 kg | |
|---|---|---|
| Product net weight | 25 kg | |
| Recommended maximum number of seated users | 4 | |
| Frame finish scratch resistance rating | 2000 cycles | |
| Surface heat resistance for hot beverage service | 80 °C | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Structural frame | Matte black powder-coated carbon steel square tubing | |
|---|---|---|
| Tabletop panel | Black laminated engineered wood substrate | |
| Lower storage shelf | Black laminated engineered wood substrate | |
| Frame connectors | Zinc-plated steel bolt and cam lock hardware | |
| Foot pads | Non-slip injection-molded polypropylene with adjustable thread | |
| Surface finish coating | Epoxy-polyester matte black powder coat | |
| Welded frame joints | Fully welded and ground smooth corner connections | |
| Edge banding | Matching black PVC edge trim on all panel edges | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Integrated lower open shelf | Fixed flat storage surface for books, magazines and small decor | |
|---|---|---|
| Adjustable foot leveling | Threaded feet rotate to compensate for 10mm floor unevenness | |
| Smooth easy-clean top surface | Non-porous finish wipes clean with dry or damp cloth | |
| Open frame leg design | Unobstructed knee and leg clearance for seated sofa users | |
| Fixed rigid frame assembly | Bolted connections prevent wobble during regular use | |
| Floor protection | Soft polymer foot pads prevent scratching hard flooring and rugs | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Packaged carton dimensions | 1240 x 640 x 203 mm | |
|---|---|---|
| Packaged gross weight | 28 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Living room seating area | Positioned directly in front of 3-seat sofas for beverage service and decor | |
|---|---|---|
| Small apartment open plan spaces | Low profile open frame minimizes visual bulk in compact areas | |
| Modern minimalist interior schemes | Uniform matte black finish complements industrial and contemporary decor | |
| Casual tea or coffee service | Smooth hard surface supports tea sets and serving trays without damage | |
| Loft and home lounge spaces | Metal construction matches exposed structural industrial design aesthetics |
EU Market Access Requirements* EN Standards
| Formaldehyde emission recommendation | EN 312 P2 grade | |
|---|---|---|
| Surface durability recommendation | EN 12720 Level 3 | |
| Structural strength recommendation | EN 15372:2016 |
Standards applicable to China-market projects
| Formaldehyde emission recommendation | GB/T 18580E1 grade | |
|---|---|---|
| Metal furniture structural safety recommendation | GB/T 3324 | |
| Surface coating adhesion recommendation | GB/T 9286Grade 1 | |
| Furniture stability recommendation | GB/T 10357.2 |
This product must meet the following technical requirements: 1. Formaldehyde emission recommendation: GB/T 18580E1 grade; 2. Metal furniture structural safety recommendation: GB/T 3324; 3. Surface coating adhesion recommendation: GB/T 9286Grade 1; 4. Furniture stability recommendation: GB/T 10357.2; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
