Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1300 x 700 x 450 mm | |
|---|---|---|
| Tabletop thickness | 12 mm | |
| Frame tube thickness | 1.2 mm | |
| Lower shelf depth | 600 mm | |
| Left closed panel height | 400 mm | |
| Right vertical slat spacing | 60 mm | |
| Floor clearance under lower shelf | 50 mm | |
| Left closed panel width | 400 mm | |
| Right slatted section width | 450 mm | |
| Middle lower shelf width | 450 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 145 kg | |
|---|---|---|
| Tabletop surface temperature resistance | 180 °C | |
| Product net weight | 55 kg | |
| Recommended user capacity | 4 people | |
| Frame anti-rust coating durability | 500 hours salt spray resistance | |
| Sintered stone surface abrasion resistance | 6000 revolutions | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | 12mm light grey sintered stone with polished matte finish | |
|---|---|---|
| Main frame | 1.2mm thick carbon steel with matte black powder coating | |
| Lower storage shelf | 8mm thick black tempered glass with frosted back finish | |
| Left side panel | 15mm thick black matte particle board panel | |
| Right vertical slats | 1.0mm thick black powder-coated carbon steel bars | |
| Frame foot pads | 5mm thick non-slip PVC pads | |
| Assembly hardware | Zinc-plated steel screws and connection brackets | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Storage configuration | Left closed hidden compartment, middle open lower shelf, right slatted open storage | |
|---|---|---|
| Tea service placement | Flat seamless tabletop accommodates standard 800mm long gongfu tea trays | |
| Floor protection | Non-slip PVC foot pads prevent floor scratches and stabilize placement | |
| Flat-pack assembly | Knock-down construction with included hardware for on-site assembly | |
| Surface maintenance | Non-porous sintered stone top resists tea stains and requires only wiping for cleaning | |
| Ventilated storage | Right vertical slat section provides air circulation for stored tea accessories | |
| Hidden storage | Left closed panel conceals small tea tools and supplies out of sight | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Living room center placement | Positioned in front of sofas for daily gongfu tea service and casual snack use | |
|---|---|---|
| Small apartment tea space | Compact 1300mm length fits 30sqm small living rooms without occupying excess space | |
| Modern minimalist interiors | Black frame and grey stone top coordinates with light grey, monochrome or industrial interior styles | |
| Home tea room setup | Sized for 4 guests to gather for casual tea tasting sessions | |
| Office reception area use | Suitable for placing in reception lounges to serve guests beverages |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Strength, durability and safety requirements for domestic living room tables | |
|---|---|---|
| EN 13722:2004 | Furniture - Assessment of surface resistance to cold liquids for table tops | |
| EN 1022:2018 | Domestic furniture - Seating and tables - Determination of stability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for left panel assembly quality | |
|---|---|---|
| GB/T 3325-2017 | General technical requirements for metal furniture, applicable for frame welding and coating quality | |
| GB 6566-2010 | Limits of radionuclides in building materials, applicable for sintered stone top radiation safety | |
| GB/T 4897.3-2017 | Particle board requirements for furniture use, applicable for left side panel material |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for left panel assembly quality; 2. GB/T 3325-2017: General technical requirements for metal furniture, applicable for frame welding and coating quality; 3. GB 6566-2010: Limits of radionuclides in building materials, applicable for sintered stone top radiation safety; 4. GB/T 4897.3-2017: Particle board requirements for furniture use, applicable for left side panel material; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
