Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1400 x 650 x 400 mm | |
|---|---|---|
| Embedded tea tray dimensions | 900 x 450 x 30 mm | |
| Leg outer width | 150 mm | |
| Metal slat thickness per leg | 20 mm | |
| Slat gap per leg assembly | 15 mm | |
| Tabletop overhang past leg | 80 mm | |
| Undertable floor clearance | 120 mm | |
| Tabletop slab thickness | 12 mm | |
| Leg assembly length along table length | 600 mm | |
| Seating clearance around perimeter | 300 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Tabletop static load capacity | 150 kg | |
|---|---|---|
| Product net weight | 55 kg | |
| Recommended seating capacity | 6 persons | |
| Stone surface scratch resistance (reference) | 6 Mohs | |
| Tea tray drainage flow rate | 1.5 L/min | |
| Metal finish corrosion resistance | 48 hours neutral salt spray | |
| Table lateral stability load | 40 kg horizontal force at top edge | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop surface | 12mm thick matte light beige sintered stone | |
|---|---|---|
| Embedded tea tray | 30mm thick polished black stone with concealed drain | |
| Leg outer panels | Matte off-white MDF panel with matching paint finish | |
| Leg internal slats | Powder-coated dark gray carbon steel vertical slats | |
| Frame understructure | Square carbon steel tube support frame with anti-corrosion primer | |
| Table underside backing | 15mm thick moisture-resistant MDF reinforcement | |
| Foot pads | Adjustable nylon anti-slip leveling feet | |
| Drain fitting | Food-grade silicone drain hose connection under tray | |
| Surface edge treatment | 45-degree chamfered polished stone edge | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Integrated tea service station | Recessed black stone tray flush with tabletop for tea set placement | |
|---|---|---|
| Concealed drainage system | Hidden drain outlet under tray connects to external waste container | |
| Leveling adjustment | Adjustable nylon feet rotate to compensate for uneven floor surfaces | |
| Surface stain resistance | Non-porous sintered stone top resists tea and water stains for easy wiping | |
| Perimeter seating support | Rectangular form allows seating on all four sides for group tea service | |
| KD assembly structure | Leg assemblies attach to underframe with bolted connections for flat-pack shipping | |
| Scratch-resistant work surface | Hard stone surface supports direct placement of teapots, cups and hot kettles | |
| Modular tray customization | Recessed tray cutout accepts matching stone or upgraded electric tea boiler units | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Office reception area | Low height suits casual guest reception and tea service for visitors | |
|---|---|---|
| Home living room lounge | Rectangular form fits open seating areas paired with sofas and low stools | |
| Private tea room | Integrated tray supports dedicated kung fu tea preparation and tasting | |
| Hotel lounge and clubhouse | Durable stone and metal construction suits high-traffic public lounge spaces | |
| Executive breakout space | Compact footprint fits informal meeting areas adjacent to office work zones | |
| Open-plan showroom display | Light neutral colorway complements modern minimalist interior design schemes |
EU Market Access Requirements* EN Standards
| EN 15372:2016 | Furniture - Strength, durability and safety requirements for non-domestic tables | |
|---|---|---|
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic tables | |
| EN 1022:2019 | Furniture - Seating and tables - Determination of stability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel leg components | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard requirements for dry indoor use, applicable to MDF understructure | |
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture | |
| GB/T 1732-1993 | Paint film impact resistance test method for metal surface finishes |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel leg components; 2. GB/T 4897.3-2003: Particleboard requirements for dry indoor use, applicable to MDF understructure; 3. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; 4. GB/T 1732-1993: Paint film impact resistance test method for metal surface finishes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
