Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (table + 4 placed chairs) | 2200 x 1600 x 760 mm | |
|---|---|---|
| Tabletop thickness | 15 mm | |
| Embedded tea service panel dimensions | 400 x 600 mm | |
| Embedded electric heating zone dimensions | 300 x 300 mm | |
| Under-table knee clearance height | 710 mm | |
| Seat height of matching dining chairs | 450 mm | |
| Chair overall dimensions | 520 x 500 x 750 mm | |
| Seat cushion width for each chair | 480 mm | |
| Seat cushion depth for each chair | 460 mm | |
| Chair backrest height from seat | 300 mm | |
| Frame leg angle from vertical | 15 degrees | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total set net weight (table + 4 chairs) | 90 kg | |
|---|---|---|
| Tabletop static load capacity | 150 kg | |
| Recommended maximum user weight per chair | 120 kg | |
| Tabletop surface heat resistance | 1200 °C | |
| Tabletop Mohs scratch hardness | 6 | |
| Tea drainage panel waste water capacity | 2 L | |
| Seating capacity | 4 people | |
| Table surface stain/water absorption rate | 0.02 % | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop surface panel | 15mm white marble-vein sintered stone, polished matte finish, rounded corners | |
|---|---|---|
| Table support frame and legs | 1.2mm thick carbon steel with black powder-coated finish, anti-rust treated | |
| Embedded tea drainage panel | Matching sintered stone slotted grate, marked with tea character, recessed installation | |
| Embedded heating cutout base | High-temperature resistant phenolic resin liner, electrical wiring pre-routed | |
| Chair frame and legs | 20mm diameter black powder-coated carbon steel tubing, welded curved back rail | |
| Chair seat upholstery | 0.8mm thick matte black faux leather, stitched edge binding | |
| Chair seat padding | 40mm thick high-density polyurethane foam, 40kg/m³ density, 45% rebound rate | |
| Floor contact pads | 5mm thick non-slip rubber pads on all leg bases | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Integrated wet tea brewing function | Recessed drainage grate routes waste tea to concealed under-table reservoir | |
|---|---|---|
| Built-in appliance heating position | Dedicated embedded cutout supports electric tea kettle boiling for kung fu tea service | |
| Fixed rigid table assembly | KD bolt-connected frame and top, non-extendable, non-tilting fixed work surface | |
| Surface maintenance function | Non-porous sintered stone top allows direct wipe cleaning, no sealing required | |
| Chair seating support | Curved backrest provides upper back support for upright tea/dining seating | |
| Frame stability function | Angled outward legs and central horizontal slatted underframe eliminate lateral wobble | |
| Waste water collection | Detachable under-table waste water bucket for easy emptying after tea service | |
| Anti-slip floor protection | Rubber foot pads prevent movement and protect hard flooring surfaces | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Small apartment dining space | Compact 1.6m length fits 4-seat dining without occupying excess floor area | |
|---|---|---|
| Office reception/tea room | Integrated tea brewing supports guest reception kung fu tea service | |
| Home living room/balcony leisure area | Multi-functional design serves both daily dining and casual tea gathering | |
| Small tea house booth seating | Matching 4-chair set provides standardized customer seating for tea service | |
| Open-plan studio space | Dual dining/tea function eliminates need for separate tea table and dining table | |
| Residential breakfast nook | 76cm standard dining height supports comfortable daily meal use |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 1022:2018 | Domestic seating – Determination of stability for chairs and stools | |
| EN 13722:2004 | Furniture – Test methods for surface resistance to dry heat |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural safety verification | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable if hidden structural panels are included | |
| GB 18584-2001 | Formaldehyde emission limit for indoor wooden furniture, applicable for E1 grade verification | |
| GB/T 15102-2017 | Performance requirements for decorative laminated surfaces, applicable for sintered stone top verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural safety verification; 2. GB/T 4897.3-2015: Particleboard for furniture use, applicable if hidden structural panels are included; 3. GB 18584-2001: Formaldehyde emission limit for indoor wooden furniture, applicable for E1 grade verification; 4. GB/T 15102-2017: Performance requirements for decorative laminated surfaces, applicable for sintered stone top verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
