PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	900 × 2200 × 762 mm
Tabletop thickness	48 mm
Rounded end radius	450 mm
Under-table knee clearance height	712 mm
Under-table legroom depth along long edge	1500 mm
Edge profile radius	20 mm
Clearance between tabletop and floor at base perimeter	0 mm
Base footprint dimensions	2100 x 800 mm
Finished Top Thickness	45 mm
Effective Knee Clearance	680 mm high and 900 mm wide per main seat
Leg / Support Section	80 mm main section with 2 mm metal wall
Cable Opening Size	80 mm diameter; cable tray depth 120 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Total table net weight	113 kg
Distributed static tabletop load capacity	150 kg
Seating capacity	8 persons
Surface heat resistance threshold	120 °C
Surface abrasion resistance rating	4 grade
Recommended static weight per seat position	110 kg
Edge impact resistance rating	2 J
Top Static Load Reference	150 kg uniformly distributed
Drawer Slide Load / Life	45 kg/pair; 50000 cycles
Hinge Opening Life	Acceptance target 80000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Tabletop surface layer	Polished white veined stone-look slab
Tabletop backing substrate	18 mm thick high-density particleboard
Base enclosure	Black ribbed matte MDF panel
Base internal frame	40 x 40 mm square steel tube, powder-coated black
Foot pads	8 mm thick adjustable nylon glides
Connector hardware	M8 steel allen bolts with lock washers
Surface finish coat on base	80 μm thick matte black powder coating
Edge banding	2 mm thick matching color PVC edge strip
Primary Panel Thickness	25 mm; load-bearing top may use 40 mm composite build-up
Edge Band Thickness	2 mm
Metal Frame Wall Thickness	2 mm cold-rolled steel
Primary Connector Specification	Reference M6-M8 with at least 2 fixing points per main support

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Table structure type	Fixed non-extendable rigid assembly
Level adjustment	±10 mm adjustable foot pad travel
Surface maintenance	Wipe-clean non-porous polished surface
Seating layout support	Dual long-edge and end seating positions
Stability performance	Low center of gravity from heavy base
Edge safety design	Fully rounded perimeter edges
Knock-down assembly design	Tabletop attaches to base with 8 mounting bolts
Cable Management Capacity	Reference capacity 10power/data cables; tray load 10 kg
Reference Reassembly Count	Main joints should support 5controlled assembly cycles

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2100× 1100× 300 mm
Reference Packaged Gross Weight	90 kg/set in 2 cartons
Reference Packaging Volume	0.55 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Residential open-plan dining room use	Accommodates 8 diners, matching modern minimalist home decor schemes
Small apartment combined dining-kitchen space	Rounded corners reduce walkway obstruction in tight layouts
Light luxury style living space configuration	Polished veined top and black ribbed base complement neutral interior palettes
Paired with cylindrical upholstered dining stools	Low-profile stools tuck fully under the table when not in use to save space
Commercial cafe or boutique restaurant seating	Durable easy-clean surface suits high-turnover light commercial dining areas
Open-concept kitchen island dining extension	Racetrack shape aligns with kitchen cabinetry for seamless integrated look

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 12521:2015 Furniture: Strength, durability and safety for domestic dining tables	Applicable for structural strength, stability, and safety performance verification
EN 15185:2011 Furniture: Assessment of surface resistance to abrasion for hard surfaces	Applicable for tabletop surface abrasion durability testing
EN 15186:2011 Furniture: Assessment of surface resistance to dry heat for hard surfaces	Applicable for tabletop heat resistance performance verification
EN 13722:2004 Furniture: Test methods for strength and durability of furniture frames	Applicable for base frame structural integrity verification

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017 General technical requirements for wooden furniture	Applicable for wooden base, substrate, hardware, and structural stability acceptance
GB/T 4897.3-2015 Particleboard for furniture use	Applicable for acceptance of tabletop substrate structural performance
GB 18584-2001 Indoor decoration materials: Limit of harmful substances in wooden furniture	Applicable for formaldehyde and VOC emission acceptance for indoor use
GB/T 17657-2013 Test methods for evaluating surface properties of wood-based panels	Applicable for surface wear, heat, and impact resistance testing

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable for wooden base, substrate, hardware, and structural stability acceptance;
2. GB/T 4897.3-2015 Particleboard for furniture use: Applicable for acceptance of tabletop substrate structural performance;
3. GB 18584-2001 Indoor decoration materials: Limit of harmful substances in wooden furniture: Applicable for formaldehyde and VOC emission acceptance for indoor use;
4. GB/T 17657-2013 Test methods for evaluating surface properties of wood-based panels: Applicable for surface wear, heat, and impact resistance testing;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · DT-RC-WV-2200

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · DT-RC-WV-2200

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · DT-RC-WV-2200Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Modern Racetrack White Veined Dining Table is a fixed non-extendable dining seating solution defined by a streamlined racetrack silhouette, blending refined modern minimalism with functional durability for residential and light commercial settings. Its visual design centers on a polished white veined stone-look tabletop with fully rounded perimeter safety edges, supported by a black ribbed matte rigid base that creates a striking high-contrast aesthetic. The table supports flexible seating layouts across both dual long edges and rounded end positions, accommodating up to 8 diners when paired with coordinating upholstered cylindrical dining stools, which tuck fully under the tabletop when not in use to minimize footprint. The base is built with a powder-coated 40x40 mm square steel internal frame, wrapped in 25 mm thick black ribbed matte MDF panels finished with an 80 μm thick matte black powder coat, supporting a low center of gravity for stable performance. The tabletop features a polished white veined stone-look surface layer mounted on an 18 mm high-density particleboard substrate, with 2 mm matching color PVC edge banding along all perimeters. Adjustable 8 mm thick nylon glides at the base allow for level adjustment to accommodate uneven floor surfaces, while M8 steel allen bolts with lock washers secure the knock-down assembly connecting the tabletop to the base. The non-porous polished surface is wipe-clean for simple maintenance, with a surface heat resistance threshold of 120 °C and abrasion resistance rated grade 4, plus edge impact resistance rated 2 J to withstand regular daily use. The table fits seamlessly across a range of spaces: it works in residential open-plan dining rooms aligned with modern minimalist decor, small combined dining-kitchen layouts where its rounded corners reduce walkway obstruction in tight spaces, light luxury styled living areas where its polished veined top and ribbed black base complement neutral interior palettes, and open-concept kitchens where its racetrack shape aligns with cabinetry for an integrated island extension look. It also suits light commercial settings including cafes and boutique restaurants, where its durable easy-clean surface supports high-turnover dining service. For procurement, note the item ships as one set across two cartons, with a reference assembly time of 40 minutes per unit, and verify on-site access can accommodate the packaged dimensions prior to delivery. Seating positions are rated for a recommended static weight per seat, and the tabletop supports a distributed static load for regular dining use.
