Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (1400mm size option) | 1400 x 700 x 750 mm | |
|---|---|---|
| Sintered stone front section width | 550 mm | |
| Wood-grain rear section width (tea preparation zone) | 850 mm | |
| Integrated recessed tea tray dimensions | 800 x 200 mm | |
| Seated knee clearance height under tabletop | 600 mm | |
| Left storage cabinet base dimensions | 400 x 700 x 720 mm | |
| Right U-frame open base span | 300 mm | |
| Main armchair seat height | 450 mm | |
| Round stool seat height | 420 mm | |
| Tabletop overhang for leg room | 50 mm | |
| Left cabinet internal storage height | 650 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Table top static load capacity | 150 kg | |
|---|---|---|
| Sintered stone surface temperature resistance | 1200 °C | |
| Sintered stone surface abrasion resistance | 6000 cycles | |
| Set total net weight (table + 1 chair + 2 stools) | 80 kg | |
| Recommended maximum user weight per seat | 150 kg | |
| Seating capacity for standard configuration | 3 people | |
| Integrated tea tray drainage capacity | 2 L | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Front tabletop section | 12mm thick polished white sintered stone | |
|---|---|---|
| Rear tabletop section | 18mm thick E1-grade engineered board with walnut wood veneer | |
| Integrated tea tray | Food-grade black melamine with recessed drain channel | |
| Left cabinet frame | 18mm thick E1-grade engineered board with light gray matte laminate | |
| Right support frame | 25mm thick solid wood-grain engineered board with U-shaped cross-brace | |
| Main armchair upholstery | 280g/m² matte PU leather with 40mm high-density foam padding | |
| Main armchair frame | 1.2mm thick matte black powder-coated steel tube | |
| Round stool upholstery | 280g/m² matte PU leather with 50mm high-density foam padding | |
| Surface finish on wood components | Scratch-resistant PU clear coat with 5H hardness | |
| Hardware fittings | Zinc-plated steel connector bolts with soft-close door hinges | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Integrated recessed tea tray | Supports both wet and dry tea brewing with built-in drain connection | |
|---|---|---|
| Left enclosed storage cabinet | Provides enclosed storage for tea sets, water buckets and tea supplies | |
| Knock-down assembly design | Flat-packed for transport, assembled with included hardware without specialized tools | |
| Optional embedded electric tea boiler | Pre-cut mounting position on rear tabletop for automatic water feed/boiler unit | |
| Spill-resistant sintered stone surface | Non-porous surface prevents tea stain penetration, wipes clean with dry cloth | |
| Open right-side leg space | Unobstructed U-frame base allows flexible stool placement for guests | |
| Leveling foot pads | Adjustable pads on base bottoms compensate for uneven floor surfaces | |
| Cable management cutout | Hidden cutout at rear of table for electric tea boiler power cords | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Small home living room tea corner | Fits compact spaces with 3-person seating for casual home tea service | |
|---|---|---|
| Office reception/meeting area | Suitable for informal client meetings and staff break tea preparation | |
| Balcony leisure space | 1200mm size option fits narrow balcony layouts for personal tea use | |
| Studio/club lounge area | Matches modern light luxury decor for shared tea tasting spaces | |
| Recommended matching configuration | Pair with 1 main armchair for host use and 2 round stools for guests as shown | |
| Surface use note | Sintered stone section holds serving ware, wood section holds brewing equipment for ergonomic use |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic dining/activity tables | |
|---|---|---|
| EN 1022:2018 | Seating furniture stability test methods for accompanying chairs and stools | |
| EN 13722:2004 | Furniture surface wear resistance test standards for laminated/veneered surfaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to table frame inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for engineered wood, applicable to board material acceptance | |
| GB/T 4100-2015 | Ceramic tile/sintered stone performance standards, applicable to tabletop inspection | |
| GB 28007-2011 | Upholstered furniture safety standards, applicable to matching chair and stools |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to table frame inspection; 2. GB 18580-2017: Formaldehyde emission limits for engineered wood, applicable to board material acceptance; 3. GB/T 4100-2015: Ceramic tile/sintered stone performance standards, applicable to tabletop inspection; 4. GB 28007-2011: Upholstered furniture safety standards, applicable to matching chair and stools; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
