Automatic mm / inch conversion · Core engineering specifications
| Overall assembled footprint | 3200 x 1400 x 900 mm | |
|---|---|---|
| Seat height (top of cushion to floor) | 450 mm | |
| Seat depth per module (front to back) | 700 mm | |
| Single straight seat module width | 700 mm | |
| Curved end module radius | 700 mm | |
| Backrest height above seat | 450 mm | |
| Backrest thickness (front to back) | 180 mm | |
| Integral side table top dimensions | 800 x 600 mm | |
| Table height above floor | 650 mm | |
| Seat cushion thickness | 120 mm | |
| Base plinth height (including glides) | 60 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total unit weight (5-module configuration) | 145 kg | |
|---|---|---|
| Per seat static load rating | 150 kg | |
| Table top static load rating | 50 kg | |
| Number of seated users (shown configuration) | 4 adults | |
| Foam density (seat cushion) | 35 kg/m³ | |
| Foam density (backrest) | 28 kg/m³ | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Backrest tilt angle (fixed) | 10 degrees | |
| Table top uniformly distributed static load rating | 50 kg | |
| Seat foam density | 35 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and backrest upholstery | Woven polyester-blend fabric in teal, wrapped over foam padding | |
|---|---|---|
| Seat cushion core | High-resilience polyurethane foam, 120 mm thick, layered over a plywood deck | |
| Backrest cushion core | Medium-density polyurethane foam, 180 mm thick, with fabric wrap | |
| Internal frame | Engineered wood (particleboard / plywood) and solid wood support rails, dowelled and screwed | |
| Integral table top | White high-pressure laminate (HPL) surface with rounded edge profile, supported by an upholstered base module | |
| Base plinth | Upholstered box base matching seat fabric, enclosing the internal frame and supporting each module | |
| Floor contact glides | Black plastic non-marking glides fitted to the underside of each module | |
| Module connectors | Plastic or metal interlocking brackets between adjacent modules (hidden) | |
| Stitching and seams | Sewn fabric seams with matching thread, clean straight joins at module edges | |
| Module interconnectors | Metal interlocking brackets with plastic caps, hidden between adjacent module side panels | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Modular reconfiguration | Units can be arranged into straight rows, S-curves, full circles, or custom layouts using hidden inter-connectors | |
|---|---|---|
| Integrated side table module | One sector-shaped table unit replaces a seat module to provide a shared worksurface within the seating layout | |
| Central double-sided backrest | Two backrest cushions form a central divide, allowing back-to-back or face-in seating configurations | |
| Armless seat modules | All seat modules are armless to maximize seat count and allow uninterrupted movement along curved runs | |
| Low-profile base with glides | Low plinth base with plastic glides allows modules to sit flat on hard or carpeted floors and be repositioned with moderate effort | |
| Non-adjustable seat and back | Seat height, seat depth, and back angle are fixed; no recline, lift, or tilt mechanisms are present | |
| Contract-grade upholstery option | Upholstery can be specified in commercial-grade fabric, faux leather, or genuine leather with matching or contrasting table tops | |
| Optional power integration | Table modules or seat modules can typically be factory-fitted with USB-A, USB-C, or wireless charging pads upon request | |
| Armless seat module design | All seat modules are armless to maximize seat count and allow uninterrupted movement along curved runs | |
| Fixed static seat and back | Seat height, seat depth and back angle are permanently fixed; no recline, lift or tilt mechanisms are present | |
| Custom upholstery specification | Upholstery can be specified in commercial-grade fabric, faux leather, or genuine leather with matching or contrasting table top finishes | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages (5-module set) | 5 cartons | |
|---|---|---|
| Standard carton size (single seat module) | 800 x 750 x 550 mm | |
| Table module carton size | 900 x 700 x 500 mm | |
| Gross weight per seat module | 32 kg | |
| Gross weight of table module | 22 kg | |
| Total shipment volume (5-module set) | 2.5 m³ | |
| Assembly time (5 modules) | 60 minutes | |
| 20 ft container loading quantity | 8 sets | |
| On-site assembly time (5 modules) | 60 minutes | |
| 20 ft GP container loading quantity | 8 sets |
Recommended spaces / users / usage modes
| Office reception and waiting areas | Ideal for visitor seating in corporate lobbies and reception zones, providing multiple seats with a shared table | |
|---|---|---|
| Open-plan office breakout zones | Suitable for informal meetings, team huddles, and relaxation areas between workstations | |
| Airport and transit lounges | Appropriate for medium-traffic public waiting areas where durable, configurable seating is required | |
| Hotel and co-working lobbies | Works as modular island seating in lobbies, lounge bars, and coworking social spaces | |
| Education and library common areas | Suitable for student collaboration, reading, and casual study in university buildings and libraries | |
| Healthcare waiting rooms | Can be used in clinic and hospital waiting areas where wipeable, commercial-grade upholstery options are specified | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1022-2:2019 | Furniture – seating – determination of stability – part 2: seating for educational and office use | |
|---|---|---|
| EN 1728:2012 | Furniture – seating – determination of strength and durability | |
| EN 527-3:2011 | Office furniture – work tables and desks – part 3: safety requirements – applicable to the integral side table module used for laptop work |
US and Canada office-furniture standards
| ANSI/BIFMA X5.4-2020 | Lounge and public seating furniture tests – applies to seat strength, back durability, and stability for commercial office lounges | |
|---|---|---|
| ANSI/BIFMA e3-2021 | Furniture sustainability standard – can be referenced for VOC emissions, material content, and recyclability targets |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable standards and test results require confirmation | |
|---|---|---|
| GB/T 28477-2012 | Upholstered furniture – general technical requirements for sofas – applies to upholstered seat and back assemblies | |
| GB 20400-2006 | Safety limit of harmful substances for leather and fur furniture – applicable if leather or faux-leather upholstery is specified | |
| GB/T 10357.3-2013 | Furniture – assessment of the ability to withstand mechanical forces – part 3: tables – applicable to the integral side table module |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable standards and test results require confirmation; 2. GB/T 28477-2012: Upholstered furniture – general technical requirements for sofas – applies to upholstered seat and back assemblies; 3. GB 20400-2006: Safety limit of harmful substances for leather and fur furniture – applicable if leather or faux-leather upholstery is specified; 4. GB/T 10357.3-2013: Furniture – assessment of the ability to withstand mechanical forces – part 3: tables – applicable to the integral side table module; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
