Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 420 x 550 mm | |
|---|---|---|
| Open left media cubby dimensions | 520 x 380 x 180 mm | |
| Single drawer internal dimensions | 520 x 380 x 130 mm | |
| Right double door cabinet internal width | 1120 mm | |
| Circular grille door cutout diameter | 420 mm | |
| Plinth base foot clearance height | 60 mm | |
| Top panel thickness | 25 mm | |
| Cable management opening diameter | 60 mm | |
| Internal cabinet shelf depth | 380 mm | |
| Drawer pull length | 120 mm | |
| Door handle length | 65 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top panel static load capacity | 80 kg | |
|---|---|---|
| Unit net weight | 52 kg | |
| Recommended maximum TV screen size | 75 in | |
| Drawer slide cycle rating | 50000 cycles | |
| Door hinge cycle rating | 80000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Top and side carcass panels | 18mm MDF core with walnut wood veneer, matte clear lacquer finish | |
|---|---|---|
| Back panel | 5mm MDF with black matte finish | |
| Drawer fronts and door panels | 18mm veneered MDF with framed edge detailing | |
| Grille slats | 12mm solid wood slats with matching walnut finish | |
| Drawer and door hardware | Zinc alloy with brushed brass finish, teardrop and curved bar pulls | |
| Drawer slides | Cold-rolled steel soft-close side-mount slides | |
| Door hinges | Cold-rolled steel concealed soft-close hinges | |
| Plinth base and feet | 18mm veneered MDF with raised curved corner feet | |
| Internal cabinet shelf | 15mm MDF with walnut veneer, adjustable position | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Open left cubby storage | Open front compartment designed for frequently accessed AV devices with rear cable pass-through | |
|---|---|---|
| Two stacked left drawers | Soft-close drawers for media accessory and remote storage, with integrated curved brass pulls | |
| Right double grille doors | Hinged doors with circular slatted grille for concealed AV equipment storage, passive ventilation for heat dissipation | |
| Cable management system | Rear 60mm diameter grommet holes aligned with open cubby and enclosed cabinet to route AV cables cleanly | |
| Adjustable internal shelf | Single position-adjustable shelf inside right cabinet to accommodate varying height AV receivers and speakers | |
| Soft-close hardware | All drawers and doors fitted with soft-close mechanisms to prevent slamming and reduce noise | |
| Elevated plinth base | Raised base with 60mm floor clearance for easy floor cleaning and airflow under the unit | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Living room media center | Positioned against a main wall to support flat-screen TVs up to 75 inches with AV component storage | |
|---|---|---|
| Apartment and small home spaces | 1800mm width fits open-plan and compact living areas without excessive footprint | |
| New Chinese style interior schemes | Walnut finish and brass circular grille hardware complements Zen, modern oriental and minimalist wood interiors | |
| Dining room sideboard use | Suitable as a dining storage unit for tableware and linens, matching matching wood dining sets | |
| Home office low storage | Can be placed under wall-mounted office monitors or as a low credenza for office equipment storage | |
| Hotel guest room media unit | Durable construction and refined finish suitable for boutique hotel guest room entertainment setups |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops – safety requirements, applicable for general storage safety | |
|---|---|---|
| EN 12521:2015 | Furniture – strength, durability and safety – requirements for domestic tables, applicable for top load verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish quality acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials – limit of harmful substances of wooden furniture, applicable for formaldehyde emissionAcceptance | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for wood-based panel structural performance checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish quality acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials – limit of harmful substances of wooden furniture, applicable for formaldehyde emissionAcceptance; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable for wood-based panel structural performance checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
