Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 450 x 850 mm | |
|---|---|---|
| Open top cubby dimensions (each) | 820 x 380 x 180 mm | |
| Floor clearance under plinth | 100 mm | |
| Single central drawer internal dimensions | 560 x 380 x 200 mm | |
| Side cabinet internal dimensions (each) | 520 x 380 x 520 mm | |
| Vertical slat width on doors | 20 mm | |
| Slat gap width on doors | 15 mm | |
| Side frame post thickness | 40 mm | |
| Top rail thickness above open cubbies | 30 mm | |
| Adjustable shelf position count (per side cabinet) | 3 positions | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Product net weight | 55 kg | |
|---|---|---|
| Top surface static load capacity | 80 kg | |
| Recommended maximum user weight for top seating | 0 kg | |
| Finish stain resistance rating | Level 4 | |
| Structural warranty period | 3 years | |
| Available color variants | 4 options | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main carcass material | 18mm thick CARB P2 grade engineered wood with walnut veneer | |
|---|---|---|
| Vertical slatted door material | 15mm thick solid walnut wood slats with matte clear lacquer | |
| Open cubby and interior liner | 5mm thick dark matte melamine backing panel | |
| Integrated end frame and top rail | 30mm thick solid walnut wood with rounded edge profiling | |
| Drawer slide hardware | 3-section full-extension cold-rolled steel ball-bearing slides | |
| Door hinge hardware | Soft-close concealed hydraulic hinges with 110-degree opening angle | |
| Adjustable cabinet shelves | 15mm thick veneered engineered wood with metal shelf pins | |
| Base plinth feet | Integrated solid wood feet with floor protection felt pads | |
| Surface finish | Matte UV-cured clear lacquer with water and stain resistance | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Upper open storage function | Dual divided open cubbies for frequently accessed items and display, no door enclosures | |
|---|---|---|
| Central drawer storage function | 3 stacked full-extension drawers for concealed storage of cutlery, linens, and small items | |
| Side cabinet ventilation function | Vertical slatted doors provide passive air circulation for stored items requiring ventilation | |
| Side door operation | Hinged soft-close doors open 110 degrees for full access to internal adjustable shelves | |
| Drawer operation | Push-to-open latch mechanism with no visible external pulls, soft-close return | |
| Anti-tip safety function | Included wall anchor strap secures cabinet to wall to prevent tipping for safety | |
| Adjustable shelf function | 3-position height adjustable shelves in each side cabinet for flexible storage of tall items | |
| Floor protection function | Felt pads on integrated feet prevent floor scratches during placement and movement | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Dining room application | Used as a buffet server along dining walls for storing tableware, linens, and serving pieces | |
|---|---|---|
| Entryway application | Placed in residential entryways for shoe storage and entry item organization with ventilated doors | |
| Living room application | Used as a low media console alternative for decor and media accessory storage in living spaces | |
| Home office application | Placed in home offices for document and office supply storage with accessible open top cubbies | |
| Target user group | Residential users seeking modern minimalist wooden storage with mixed open and concealed storage | |
| Recommended clearance around unit | 1000 mm clearance in front of cabinet to allow full door and drawer opening access | |
| Assembly requirement | Requires 2-person assembly with included hex key and instruction manual, no special tools needed |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops safety requirements, applicable for safety compliance reference | |
|---|---|---|
| EN 71-3:2019 | Migration of certain elements, applicable for surface finish safety reference for residential use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and dimensionalAcceptance inspectionreference | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances in wooden furniture, applicable for emission testing reference |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and dimensionalAcceptance inspectionreference; 2. GB 18584-2001: Indoor decoration material limit of harmful substances in wooden furniture, applicable for emission testing reference; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
