Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 401 x 610 mm | |
|---|---|---|
| Central open compartment width | 700 mm | |
| Central open compartment height per shelf | 210 mm | |
| Central open compartment depth | 360 mm | |
| Lower central drawer internal dimensions | 650 x 330 x 110 mm | |
| Side cabinet door dimensions per door | 520 x 490 mm | |
| Side cabinet internal storage width per bay | 490 mm | |
| Top panel thickness | 25 mm | |
| Plinth base height | 40 mm | |
| Cable management opening diameter | 60 mm | |
| Adjustable shelf thickness | 18 mm | |
| Slat grille opening width | 12 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top panel static load capacity | 113 kg | |
|---|---|---|
| Maximum supported TV size | 85 inch | |
| Product net weight | 80 kg | |
| Hinge cycle rating | 50000 open/close cycles | |
| Drawer slide cycle rating | 30000 open/close cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Frame and outer carcass | Rubber wood solid wood frame with walnut grain finish | |
|---|---|---|
| Central open shelf interior back panel | 15mm MDF with matte dark brown finish | |
| Slatted door fronts | Solid wood vertical slats matching frame finish | |
| Top surface finish | Walnut wood veneer with matte protective lacquer | |
| Drawer front panel | 18mm engineered wood with matching walnut veneer | |
| Door and drawer hardware | Brass-toned zinc alloy pulls and hinges | |
| Drawer slides | Side-mounted 3-section ball bearing metal slides | |
| Internal cabinet shelves | 18mm particle board with matching laminate finish | |
| Plinth base | Solid wood frame matching main carcass | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Two side hinged slatted doors | Open outward to reveal concealed single-shelf storage compartments | |
|---|---|---|
| Central two-tier open shelving | Provides unobstructed access for AV receivers and media players | |
| Lower central soft-close drawer | Opens via horizontal pull to store remotes, cables and small accessories | |
| Rear cable management grommets | Route AV power and HDMI cables between open shelves and wall outlets | |
| Side cabinet adjustable shelves | Support 3 height positions for flexible storage of tall media items | |
| Flush plinth base design | Sits directly on floor with no gap for dust accumulation below | |
| Ventilated slatted door design | Allows passive airflow for enclosed AV equipment to prevent overheating | |
| Rounded raised top edge trim | Prevents items placed on top from sliding off the console surface | |
| Cable / Vent Opening Reference | 80 mm diameter; recommend 4rear cable/vent openings |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living room | Placed against wall under wall-mounted or stand-mounted flat screen TVs | |
|---|---|---|
| Small apartment living spaces | Compact low-profile design fits limited floor space for media setup | |
| Zen/Japandi/New Chinese interior styles | Walnut wood finish and slatted grille design matches minimalist natural decor | |
| Home media room setup | Open shelves accommodate AV receivers, game consoles and set-top boxes | |
| Open plan living/dining areas | Low height does not block sightlines across open plan spaces | |
| Commercial lounge or waiting area | Provides media storage and display for guest entertainment areas |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and structural requirements for domestic and kitchen storage furniture, applicable for load testing | |
|---|---|---|
| EN 12521:2015 | Strength, durability and safety requirements for domestic seating, reference for hardware cycle standards | |
| EN 71-3:2019 | Migration of certain elements, applicable for hardware finish safety verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural quality checks | |
|---|---|---|
| GB/T 4893.1-2021 | Surface wear resistance test for furniture surfaces, applicable for finish durability verification | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural quality checks; 2. GB/T 4893.1-2021: Surface wear resistance test for furniture surfaces, applicable for finish durability verification; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
