Automatic mm / inch conversion · Core engineering specifications
| 3-seater sofa overall dimensions | 2050 x 850 x 850 mm | |
|---|---|---|
| Single armchair overall dimensions | 920 x 850 x 850 mm | |
| Coffee table overall dimensions | 1200 x 600 x 450 mm | |
| Seat height from floor | 420 mm | |
| Seat depth (usable) | 550 mm | |
| Armrest height from floor | 620 mm | |
| Backrest height above seat | 430 mm | |
| Coffee table lower shelf clearance | 180 mm | |
| Seat cushion thickness | 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Single sofa seat static load capacity | 150 kg | |
|---|---|---|
| Total set net weight range | 185 kg | |
| Recommended total occupant capacity | 5 persons | |
| Seat foam density | 40 kg/m³ | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Seam stitch pitch | 8 stitches per inch | |
| Maximum total occupant capacity | 5 persons | |
| Reinforced seam stitch pitch | 8 stitches per inch | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Sofa seat and back upholstery | Black matte faux leather (PU) | |
|---|---|---|
| Sofa outer side panel upholstery | Warm brown matte faux leather (PU) | |
| Seat core padding | High-density polyurethane foam | |
| Sofa internal frame | 20mm thick kiln-dried hardwood + 1.2mm steel support bars | |
| Sofa base glides | Black non-marking plastic floor glides | |
| Coffee table top | 8mm thick black tempered glass with polished silver trim edge | |
| Coffee table frame and lower shelf | 1.2mm thick matte black powder-coated steel | |
| Armrest padding | 20mm thick high-density foam wrapped in matching black faux leather | |
| Seat, backrest and armrest top upholstery | 1.0mm thick matte black polyurethane (PU) leather | |
| Seating outer side panel upholstery | 1.0mm thick matte saddle brown polyurethane (PU) leather | |
| Seat and back core padding | 40kg/m³ high-resilience polyurethane foam | |
| Seating internal load-bearing frame | 20mm thick kiln-dried hardwood with 1.2mm thick steel cross-support bars |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | Fixed modular set with 1 three-seat sofa and 2 matching single armchairs | |
|---|---|---|
| Seat support | Fixed non-tilting, non-reclining padded seat base | |
| Coffee table storage | Two-tier open storage with upper glass top and lower solid steel shelf | |
| Floor protection | Non-marking fixed glides on all seating and table legs | |
| Upholstery maintenance | Smooth non-porous faux leather surface that wipes clean with standard office cleaning products | |
| Placement flexibility | Freestanding units that can be arranged in symmetrical face-to-face, L-shape or linear layouts | |
| Seat support mechanism | Fixed non-tilting, non-reclining rigid padded seat base | |
| Coffee table storage design | Two-tier open storage with upper glass top and lower steel shelf | |
| Floor protection feature | Fixed non-marking glides installed on all seating and table legs | |
| Upholstery maintenance property | Non-porous smooth PU leather surface that wipes clean with neutral office cleaning products in 1 minute | |
| Layout flexibility | Freestanding individual units that support symmetrical face-to-face, L-shaped or linear placement | |
| Armrest functionality | Wide flat padded armrests supporting 10kg vertical load |
Verified carton / gross weight / assembly / loading data
| Total shipping carton count | 4 cartons | |
|---|---|---|
| Largest carton dimensions (3-seater sofa) | 2100 x 900 x 600 mm | |
| Total shipment gross weight | 210 kg | |
| Total shipment volume | 1.8 CBM | |
| On-site assembly time | 40 minutes | |
| 20ft GP container loading quantity | 18 sets | |
| 40ft HQ container loading quantity | 44 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Corporate office reception areas | Formal two-tone design creates a professional first impression for visitors, with seating for 5 people suitable for small guest greeting areas | |
|---|---|---|
| Executive office waiting zones | Durable easy-clean upholstery and structured support suits short-term waiting use outside senior management offices | |
| Small meeting lounge spaces | Symmetrical configuration paired with central coffee table supports casual team discussions or client breakout meetings | |
| Public institution visitor areas | High-wear faux leather and solid frame construction tolerates high daily foot traffic in government, bank or healthcare waiting spaces | |
| Recommended matching configuration | Pair with the included black glass coffee table to create a complete ready-to-install reception set, no additional side tables required for basic use | |
| Corporate main reception areas | Formal two-tone black and brown design creates a professional first impression for visitors, with 5-person capacity suitable for 20sqm small-to-medium guest greeting zones | |
| Small informal meeting lounges | Symmetrical 3+1+1 configuration paired with central coffee table supports 60 minute casual team discussions or client breakout meetings | |
| Public service institution visitor areas | High-wear PU upholstery and rigid steel-reinforced frame tolerates high daily foot traffic in bank, government service hall or healthcare admin waiting spaces |
EU Market Access Requirements* EN Standards
| Applicable standard for office seating strength and stability | EN 16139:2013 Furniture - Strength, durability and safety - Non-domestic seating | |
|---|---|---|
| Applicable standard for upholstery fire performance | EN 1021:2014 Furniture - Assessment of the ignitability of upholstered furniture - Ignition source smouldering cigarette | |
| Non-domestic seating strength reference | EN 16139:2013 Furniture - Strength, durability and safety - Non-domestic seating | |
| Upholstered furniture fire safety reference | EN 1021:2014 Furniture - Assessment of the ignitability of upholstered furniture - Part 1: Ignition source smouldering cigarette |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| Applicable standard for upholstered furniture durability | GB/T 3324 General technical requirements for wooden furniture | |
|---|---|---|
| Applicable standard for leather/faux leather upholstery | GB/T 16799 Polyurethane synthetic leather for furniture | |
| Applicable standard for tempered glass safety | GB 15763.2 Safety glazing materials in building - Part 2: Tempered glass | |
| Upholstered furniture structural durability reference | GB/T 3324 General technical requirements for wooden furniture | |
| Furniture PU leather performance reference | GB/T 16799 Polyurethane synthetic leather for furniture | |
| Tempered glass safety reference | GB 15763.2 Safety glazing materials in building - Part 2: Tempered glass |
This product must meet the following technical requirements: 1. Applicable standard for upholstered furniture durability: GB/T 3324 General technical requirements for wooden furniture; 2. Applicable standard for leather/faux leather upholstery: GB/T 16799 Polyurethane synthetic leather for furniture; 3. Applicable standard for tempered glass safety: GB 15763.2 Safety glazing materials in building - Part 2: Tempered glass; 4. Upholstered furniture structural durability reference: GB/T 3324 General technical requirements for wooden furniture; 5. Furniture PU leather performance reference: GB/T 16799 Polyurethane synthetic leather for furniture; 6. Tempered glass safety reference: GB 15763.2 Safety glazing materials in building - Part 2: Tempered glass; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
