Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1600 x 400 x 900 mm | |
|---|---|---|
| Leg height | 150 mm | |
| Individual drawer front dimensions | 460 x 130 mm | |
| Individual cabinet door dimensions | 700 x 500 mm | |
| Adjustable interior shelf thickness | 18 mm | |
| Interior cabinet compartment clearance height | 350 mm | |
| Top surface overhang | 20 mm | |
| Hexagonal carved inlay size per door | 220 x 300 mm | |
| Drawer internal depth | 340 mm | |
| Floor clearance under cabinet base rail | 120 mm | |
| Gold ferrule height per leg | 15 mm | |
| Knob diameter per drawer/door | 30 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 50 kg | |
|---|---|---|
| Overall product net weight | 62 kg | |
| Recommended maximum user weight for top surface standing | 80 kg | |
| Drawer slide cycle durability | 50000 cycles | |
| Door hinge cycle durability | 80000 cycles | |
| Anti-tip device static load resistance | 50 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet carcass | 18mm E1 grade engineered wood substrate with walnut grain veneer | |
|---|---|---|
| Drawer fronts | 15mm MDF substrate with matte light blue paint finish | |
| Support legs | 50mm diameter solid rubberwood tapered legs with gold powder-coated metal ferrules | |
| Cabinet doors | 20mm solid wood framed panels with hexagonal carved wood inlays | |
| Back panel | 5mm thick hardboard with walnut grain finish | |
| Hardware (knobs) | Zinc alloy round knobs with brushed gold finish | |
| Edge banding | 1mm thick PVC edge banding matching walnut finish | |
| Coating finish | Water-based matte wood lacquer with 10% wood moisture content control | |
| Drawer slides | Cold-rolled steel side-mounted full extension slides | |
| Door hinges | Cold-rolled steel soft-close concealed hinges | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Upper storage | Three equal-sized soft-close drawers for small entryway item organization | |
|---|---|---|
| Lower storage | Two hinged doors enclosing two adjustable-height storage shelves | |
| Door operation | 110 degree opening angle for easy access to interior compartments | |
| Safety feature | Two wall-mounted anti-tip connectors to prevent forward tipping | |
| Surface use | Flat sealed top surface for decorative display and small household items | |
| Drawer operation | Full extension drawer travel with soft-close damping to prevent slamming | |
| Cleaning feature | Elevated leg design enabling 120mm floor clearance for robot vacuum access | |
| Shelf adjustability | Five shelf pin positions allowing 50mm incremental height adjustment | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Entryway/foyer placement | Positioned against entrance walls for key, accessory and shoe storage | |
|---|---|---|
| Living room sideboard use | Placed behind sofas or along walls for media accessory and display storage | |
| Dining room buffet use | Installed adjacent to dining tables for tableware and linen storage | |
| Residential home use | Suitable for private homes, apartments and small residential lobbies | |
| Matching interior style | Coordinated with new Chinese, modern oriental and contemporary walnut interiors | |
| Top surface display | Used to hold art, vases, figurines and decorative tabletop items |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units worktops safety requirements for structural stability | |
|---|---|---|
| EN 12521:2015 | Furniture strength durability safety for domestic seating adjacent storage | |
| EN 71-3:2019+A1:2021 | Migration of certain elements for painted surface safety compliance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to substrate performance requirements | |
| GB/T 1931-2009 | Wood moisture content determination method for solid wood components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional and structural acceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture; 3. GB/T 4897.3-2003: Particleboard for furniture use, applicable to substrate performance requirements; 4. GB/T 1931-2009: Wood moisture content determination method for solid wood components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
