Automatic mm / inch conversion · Core engineering specifications
| Overall product dimensions | 1400 x 425 x 880 mm | |
|---|---|---|
| Leg height | 120 mm | |
| Individual upper drawer dimensions (each) | 560 x 350 x 120 mm | |
| Left double-door cabinet compartment width | 840 mm | |
| Right single-door cabinet compartment width | 560 mm | |
| Top surface thickness | 25 mm | |
| Door panel thickness | 18 mm | |
| Adjustable shelf thickness inside cabinet | 16 mm | |
| Back panel thickness | 9 mm | |
| Kick clearance under cabinet | 120 mm | |
| Drawer front height | 120 mm | |
| Brass drawer pull diameter | 40 mm | |
| Brass vertical door pull length | 95 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 30 kg | |
|---|---|---|
| Product net weight | 60 kg | |
| Recommended maximum loaded weight | 130 kg | |
| Edge band thickness | 1 mm | |
| Hinge opening angle | 105 degrees | |
| Hinge cycle durability | 80000 open/close cycles | |
| Drawer slide cycle durability | 50000 open/close cycles | |
| Standard warranty period | 3 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass material | 18mm E1 grade engineered wood with dark walnut wood grain finish | |
|---|---|---|
| Top surface material | 25mm medium density fiberboard with matte walnut wood veneer finish | |
| Door panel construction | 18mm engineered wood with recessed panel frame, semicircular vertical slat inserts on left doors | |
| Leg material | Solid engineered wood square profile with brass-finish metal foot caps | |
| Hardware material | Zinc alloy with brushed brass finish, including circular drawer pulls and vertical bar handles | |
| Back panel material | 9mm hardboard with dark brown matching finish | |
| Shelf material | 16mm adjustable engineered wood with matching edge banding | |
| Drawer slide material | Cold-rolled steel with black electroplated finish, three-quarter extension | |
| Hinge material | Cold-rolled steel with soft-close damping function | |
| Surface finish | Matte polyurethane wood coating, scratch-resistant and easy to clean | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Upper drawer storage | 2 independent shallow drawers for small entry items, opened by circular brass pulls | |
|---|---|---|
| Left cabinet storage | Double doors with semicircular slat details, one adjustable shelf for tall item storage | |
| Right cabinet storage | Single recessed-panel door, one fixed shelf for medium-sized items storage | |
| Door operation | Hinged doors open to 105 degrees, soft-close mechanism prevents slamming | |
| Drawer operation | Three-quarter extension steel slides, smooth pull-out action for easy access to stored items | |
| Top display function | Flat level top surface supports decorative vases, art objects and daily essentials | |
| Anti-tip safety | Includes 2 wall anchor connectors to prevent tipping when loaded or doors are opened | |
| Cleaning function | Smooth matte surface is stain-resistant, can be wiped clean with dry or damp soft cloth | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Entryway application | Placed against wall at entry foyer to store keys, bags, shoes and display decorative pieces | |
|---|---|---|
| Dining room application | Used as dining sideboard to store tableware, linens and tea sets beside dining table | |
| Living room application | Positioned below wall art in living room to store media accessories and display ornaments | |
| Tea room application | Suitable for Zen-style tea rooms to store tea sets, tea canisters and tea accessories | |
| Target user group | Residential users preferring New Chinese style furniture for home storage needs | |
| Recommended matching decor | Pairs with dark wood furniture, brass light fixtures and neutral stone or wood flooring |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to dimensional tolerance and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade ≤0.124mg/m³ requirement | |
| GB/T 4893.8-2013 | Surface furniture wear resistance test method, minimum 400 revolution requirement | |
| GB/T 10357.5-2011 | Furniture mechanical performance test for storage units, shelf and drawer load test |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to dimensional tolerance and finish quality; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 grade ≤0.124mg/m³ requirement; 3. GB/T 4893.8-2013: Surface furniture wear resistance test method, minimum 400 revolution requirement; 4. GB/T 10357.5-2011: Furniture mechanical performance test for storage units, shelf and drawer load test; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
