Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 400 x 920 mm | |
|---|---|---|
| Upper drawer dimensions (per unit) | 570 x 370 x 150 mm | |
| Lower cabinet door height | 670 mm | |
| Internal shelf depth (per compartment) | 360 mm | |
| Clearance under cabinet base | 50 mm | |
| Top surface display thickness | 18 mm | |
| Gold trim width (edges/doors) | 8 mm | |
| Handle length (drawers/doors) | 90 mm | |
| Internal adjustable shelf height per bay | 320 mm | |
| Back panel thickness | 3 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Top surface static load capacity | 50 kg | |
|---|---|---|
| Total unit net weight | 60 kg | |
| Hinge open/close cycle rating | 80000 cycles | |
| Drawer slide cycle rating | 50000 cycles | |
| Recommended maximum stored item height in lower cabinet | 300 mm | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet carcass | 18mm thick E1-grade engineered MDF/particleboard | |
|---|---|---|
| Lower door panels | Walnut wood veneer finish over engineered wood core | |
| Upper drawer fronts | Matte cream/ivory PU lacquer finish over engineered wood | |
| Edge and door/drawer trim | Polished gold-plated iron alloy trim | |
| Hardware (handles/hinges/slides) | Gold-plated zinc alloy handles, cold-rolled steel concealed hinges, side-mounted ball-bearing slides | |
| Top surface | Stain-resistant laminate/veneer matching carcass finish | |
| Back panel | 3mm thick hardboard (MDF) | |
| Base support feet | Hidden plastic/metal feet with 50mm floor clearance | |
| Edge banding | Matching PVC edge banding on internal cut edges, protected by external gold trim | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Upper drawer storage | Two equal-width soft-close drawers with horizontal gold bar pulls, opening fully on side-mounted ball-bearing slides for small item access | |
|---|---|---|
| Lower cabinet storage | Three vertical hinged doors, each fitted with an adjustable/removable shelf to customize compartment height for larger items | |
| Door operation | Concealed 105-degree opening hinges allow unobstructed access to internal storage without protruding into walkways | |
| Top display function | Flat, level top surface supports decorative objects, table lamps, and entryway essentials with no raised edge lip | |
| Wall installation compatibility | Pre-drilled anti-tip anchor points for securing to wall to prevent tipping when fully loaded | |
| Surface maintenance | Wipe-clean smooth lacquer and veneer surfaces require only damp cloth cleaning, no special treatment required | |
| Leveling adjustment | Small adjustable feet at base allow leveling on uneven marble or wood flooring | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential entryway/foyer use | Placed against entry wall for storing keys, mail, shoes, and entry accessories with top space for decorative display | |
|---|---|---|
| Dining room sideboard/buffet use | Positioned along dining room wall for storing tableware, linens, and serving pieces with top for serving platters or decor | |
| Living room accent storage use | Used against living room wall for media accessories, books, and household items, paired with wall art for modern luxury styling | |
| Small apartment space optimization | 1200mm compact width fits small urban apartments without occupying excessive floor space, maximizing vertical storage | |
| Luxury modern/light luxury interior schemes | Walnut and cream two-tone finish with gold trim matches contemporary light luxury, modern classic, and new Chinese interior design styles |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and performance requirements for domestic storage furniture, including anti-tip stability testing | |
|---|---|---|
| EN 12521:2015 | Durability and strength requirements for freestanding domestic storage furniture for residential use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional tolerance, structural strength, and finish quality inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, minimum E1 grade required for indoor residential use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional tolerance, structural strength, and finish quality inspection; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, minimum E1 grade required for indoor residential use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
