Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 1800 x 760 mm | |
|---|---|---|
| Central lazy Susan turntable diameter | 900 mm | |
| Tabletop total thickness | 26 mm | |
| Table edge solid wood trim thickness | 20 mm | |
| Pedestal base maximum diameter (foot) | 800 mm | |
| Pedestal base minimum diameter (waist) | 450 mm | |
| Brass foot trim ring width | 30 mm | |
| Under-table seated knee clearance height | 680 mm | |
| Per-person seated edge space | 706 mm | |
| Required minimum room size for use | 3500 x 3500 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed static tabletop load capacity | 150 kg | |
|---|---|---|
| Lazy Susan rotating bearing fatigue life | 100000 cycles | |
| Seating capacity | 8 people | |
| Product net weight | 120 kg | |
| Wood core moisture content | 12% | |
| Tabletop surface wear resistance | 2000 abrasion cycles | |
| Brass trim corrosion resistance | Grade 4 salt spray rating | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | High-density E0 grade fiberboard core | |
|---|---|---|
| Tabletop surface veneer | Sunburst book-matched walnut wood veneer | |
| Table edge trim | Solid walnut wood edge banding | |
| Lazy Susan turntable | Walnut veneer matching tabletop finish, steel ball bearing swivel | |
| Pedestal base structure | Curved engineered wood frame with matching walnut veneer finish | |
| Pedestal foot trim | Brushed brass-finish stainless steel ring | |
| Surface finish | Matte wear-resistant PU lacquer | |
| Assembly hardware | Zinc-plated steel connector bolts and floor glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Lazy Susan rotation mechanism | 360-degree manual smooth rotation on sealed ball bearings | |
|---|---|---|
| Floor protection | Non-marking adjustable plastic glides at pedestal base | |
| Assembly configuration | Knock-down flat-pack construction, tabletop attaches to pedestal with included hardware | |
| Structural stability | Wide weighted pedestal base eliminates table leg obstructions for all seating positions | |
| Spill resistance | Sealed lacquer finish prevents liquid penetration into wood veneer | |
| Turntable load capacity | 30 kg distributed load | |
| Edge safety design | Rounded 5mm radius table edge eliminates sharp corners | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining room use | Suitable for 8-person family meals and gatherings in mid-century modern homes | |
|---|---|---|
| Small private restaurant dining | Usable for boutique private dining rooms serving shared cuisine | |
| Open-plan living space placement | Pedestal design eliminates protruding legs for flexible layout arrangements | |
| Matching furniture configuration | Pairs with upholstered mid-century dining chairs with dark wood legs | |
| Commercial hospitality lounge use | Suitable for upscale lounge breakout areas for casual group seating |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety requirements for domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Furniture test methods for table surface resistance to cold liquids and abrasion | |
| EN 71-3:2019+A1:2021 | Migration of certain elements for furniture used in residential indoor settings |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood dining table structural safety | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, formaldehyde emission ≤1.5mg/L | |
| GB/T 4893.8-2013 | Furniture surface test for wear resistance, applicable to tabletop lacquer finish durability | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, static load and stability testing requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood dining table structural safety; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, formaldehyde emission ≤1.5mg/L; 3. GB/T 4893.8-2013: Furniture surface test for wear resistance, applicable to tabletop lacquer finish durability; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, static load and stability testing requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
