Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1520 x 1520 x 760 mm | |
|---|---|---|
| Central lazy Susan diameter | 800 mm | |
| Tabletop thickness | 23 mm | |
| Pedestal base diameter | 800 mm | |
| Under-table knee clearance height | 680 mm | |
| Tabletop edge radius | 15 mm | |
| Lazy Susan recess depth | 3 mm | |
| Per-person seating width allocation | 600 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Recommended seating capacity | 8 seats | |
|---|---|---|
| Distributed tabletop static load | 150 kg | |
| Lazy Susan rotating load capacity | 50 kg | |
| Table net weight | 77 kg | |
| Finish surface abrasion resistance | 2000 cycles | |
| Wood moisture content | 10% | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer tabletop | Solid hardwood with dark espresso polyurethane finish | |
|---|---|---|
| Central lazy Susan surface | White matte sintered stone | |
| Lazy Susan rotating mechanism | Steel ball-bearing turntable ring | |
| Central pedestal column | Solid hardwood with matching dark finish | |
| Circular base plate | Solid hardwood with dark lacquer finish | |
| Structural hardware | Zinc-plated steel connector bolts | |
| Table edge banding | Solid wood matching veneer finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Lazy Susan rotation | 360° free-spinning rotation | |
|---|---|---|
| Seating access | Obstruction-free leg clearance around full circumference | |
| Surface protection | Scratch and heat resistant lazy Susan surface | |
| Assembly design | Knock-down 3-piece assembly | |
| Floor contact | Non-marking felt pads on base bottom | |
| Fixed tabletop design | Non-extendable fixed round top | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 carton | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining room | Suitable for 8-person family meals and holiday gatherings | |
|---|---|---|
| Private restaurant dining room | Ideal for small private dining booths in Chinese cuisine restaurants | |
| Hotel banquet suite | Appropriate for small event hospitality setups | |
| Recommended pairing | Matches dark wood frame dining chairs with light upholstered seats | |
| Floor surface compatibility | Safe for hardwood, tile and laminate flooring |
EU Market Access Requirements* EN Standards
| Domestic furniture tables safety requirements | EN 12521:2015 | |
|---|---|---|
| Furniture surface resistance assessment | EN 12720:2013 |
Standards applicable to China-market projects
| Wood furniture general technical requirement | GB/T 3324 | |
|---|---|---|
| Furniture mechanical performance test for tables | GB/T 10357.1 | |
| Wood furniture harmful substance limit | GB 18584 |
This product must meet the following technical requirements: 1. Wood furniture general technical requirement: GB/T 3324; 2. Furniture mechanical performance test for tables: GB/T 10357.1; 3. Wood furniture harmful substance limit: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
