Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 2400 × 760 mm | |
|---|---|---|
| Overall table dimensions | 2400 x 2400 x 760 mm | |
| Central lazy Susan diameter | 1400 mm | |
| Sintered stone outer ring width | 500 mm | |
| Tabletop total thickness | 50 mm | |
| Pedestal base diameter | 2200 mm | |
| Pedestal base height | 700 mm | |
| Knee clearance height under apron | 650 mm | |
| Gold metal trim thickness | 10 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended seating capacity | 15 people | |
|---|---|---|
| Distributed static tabletop load | 750 kg | |
| Lazy Susan static load capacity | 150 kg | |
| Net product weight | 400 kg | |
| Sintered stone surface abrasion resistance | 6000 revolutions | |
| Structure service life | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Outer tabletop ring | 12mm dark sintered stone, scratch and stain resistant | |
|---|---|---|
| Inner tabletop ring | Walnut-toned engineered wood veneer over 38mm MDF core | |
| Central lazy Susan | Solid walnut wood veneer rotating turntable with quiet bearing | |
| Pedestal fluted panels | Champagne beige PU finish over 18mm MDF with vertical flute detail | |
| Pedestal framing | Solid hardwood internal frame with reinforced corner blocks | |
| Decorative trim | Brushed gold stainless steel edging at pedestal seams and base | |
| Base plinth | Walnut wood veneer bottom ring with protective floor glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lazy Susan rotation | 360° smooth rotation on central heavy-duty bearing, no fixed stop positions | |
|---|---|---|
| Table assembly | Knocked-down construction with bolted pedestal-to-top connection for on-site installation | |
| Surface maintenance | Non-porous sintered stone outer ring allows wipe-clean sanitization between banquet services | |
| Leveling adjustment | Integrated adjustable floor glides at base plinth to compensate for uneven flooring | |
| Customization option | Supports pre-drilled induction cooktop cutouts per custom order | |
| Rotation upgrade option | Compatible with aftermarket electric motor drive for automated lazy Susan rotation | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Hotel private dining rooms | Ideal for 16 guest formal banquet service in upscale hospitality venues | |
|---|---|---|
| High-end Chinese restaurants | Suits premium business banquet and group dining service with shared dish access | |
| Corporate executive dining spaces | Appropriate for executive guest entertainment and large internal group meals | |
| Luxury residential large dining areas | Fits high-end villa grand dining rooms for large family gatherings and events | |
| Recommended pairing | Matches 15 walnut-framed upholstered light-beige dining chairs for full set configuration |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Furniture mechanical safety | EN 12521:2015 Furniture - Strength, durability and safety for domestic dining tables | |
|---|---|---|
| Surface resistance to cold liquids | EN 12720:2013 Furniture - Assessment of surface resistance to cold liquids |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Table dimensional tolerance | GB/T 3324General technical requirements for wooden furniture | |
|---|---|---|
| Surface adhesion performance | GB/T 4893.4Furniture surface paint film adhesion test | |
| Formaldehyde emission limit | GB 18584Indoor decorating and refurbishing materials - limit of formaldehyde emission |
This product must meet the following technical requirements: 1. Table dimensional tolerance: GB/T 3324General technical requirements for wooden furniture; 2. Surface adhesion performance: GB/T 4893.4Furniture surface paint film adhesion test; 3. Formaldehyde emission limit: GB 18584Indoor decorating and refurbishing materials - limit of formaldehyde emission; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
