Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2200 mm diameter × 760 mm height | |
|---|---|---|
| central turntable diameter | 1540 mm | |
| dark wood outer ring width | 330 mm | |
| light stone middle ring width | 330 mm | |
| tabletop total thickness | 50 mm | |
| pedestal base diameter | 1900 mm | |
| pedestal base height | 710 mm | |
| seated knee clearance height | 680 mm | |
| gold decorative inlay width | 10 mm | |
| pedestal support foot footprint | 120 × 120 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| net product weight | 180 kg | |
|---|---|---|
| distributed tabletop static load capacity | 300 kg | |
| recommended seating capacity | 12 people | |
| turntable rotation speed (electric variant) | 4 rpm | |
| surface scratch resistance rating | Grade 2 | |
| surface heat resistance temperature | 120 °C | |
| structural warranty period | 3 years | |
| electric motor warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| outer tabletop ring | High-gloss dark ebony-stained solid wood veneer over multi-layer board | |
|---|---|---|
| middle tabletop ring | Polished light grey sintered stone/engineered stone panel | |
| central turntable | High-gloss dark solid wood/sintered stone panel with steel rotating bearing | |
| pedestal frame | Thick multi-layer solid wood frame with dark high-gloss paint finish | |
| pedestal panel inserts | Matte light grey painted MDF/acrylic panels | |
| decorative accents | Polished gold-finish stainless steel inlay strips | |
| internal support frame | 2mm thick welded square steel tube internal reinforcement | |
| surface coating | Scratch-resistant high-gloss polyurethane paint finish | |
| table edge trim | 40mm thick rounded solid wood edge banding | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| central turntable rotation | 360° smooth rotation via silent electric motor (remote controlled) | |
|---|---|---|
| turntable speed adjustment | 3 adjustable rotation speeds via handheld remote control | |
| disassembly for transport | Tabletop separates from pedestal base for freight and installation | |
| surface waterproof performance | Sealed high-gloss finish resists liquid spills and staining | |
| leveling adjustment | Adjustable feet at pedestal base feet for uneven floor alignment | |
| optional hot pot integration | Pre-drilled mounting points available for built-in induction cookers | |
| anti-tip stability | Wide weighted pedestal base prevents tipping when turntable is fully loaded | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| hotel private dining rooms | Suitable for 12-guest formal banquet service with central shared dish access | |
|---|---|---|
| high-end Chinese restaurant banquet halls | Matches new Chinese interior decor for premium group dining service | |
| large residential formal dining rooms | Suitable for extended family meals and large home entertaining events | |
| corporate executive dining spaces | Appropriate for formal business reception dining and hosted events | |
| private club and VIP lounge dining areas | Fits upscale traditional decor for member exclusive dining service |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety requirements for domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for surface resistance to dry heat for furniture surfaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural safety and finish quality | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde and heavy metal content | |
| GB/T 4893.4-2013 | Surface wear resistance test for furniture surfaces, applicable to tabletop finish durability | |
| GB/T 4893.3-2020 | Surface heat resistance test for furniture, applicable to hot serving ware contact performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural safety and finish quality; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde and heavy metal content; 3. GB/T 4893.4-2013: Surface wear resistance test for furniture surfaces, applicable to tabletop finish durability; 4. GB/T 4893.3-2020: Surface heat resistance test for furniture, applicable to hot serving ware contact performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
