| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 1800 x 770 mm | |
|---|---|---|
| Tabletop thickness | 50 mm | |
| Central lazy Susan diameter | 1200 mm | |
| Lazy Susan thickness | 30 mm | |
| Cylindrical pedestal base diameter | 600 mm | |
| Pedestal base height | 720 mm | |
| Bottom metal foot trim diameter | 650 mm | |
| Metal foot trim thickness | 20 mm | |
| Seating clearance per place setting | 680 mm | |
| Under-table leg clearance height | 670 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total product net weight | 75 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 250 kg | |
| Recommended seating capacity | 8 people | |
| Wood surface scratch resistance rating | 2H pencil hardness | |
| Finish heat resistance temperature | 80 °C | |
| Structural frame warranty period | 3 years | |
| Finish warranty period | 1 year | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main tabletop material | Walnut-finished solid hardwood, 50mm thick, matte clear polyurethane coating | |
|---|---|---|
| Central lazy Susan material | Matching solid hardwood with smooth edge, fitted with steel rotating bearing | |
| Cylindrical pedestal base | Walnut wood veneer over engineered wood core, vertical grain matching tabletop | |
| Bottom foot trim ring | Dark matte coated carbon steel, 20mm thick, floor-protective felt lining | |
| Lazy Susan rotating bearing | Zinc-plated steel ball bearing, 360° rotation, low-friction design | |
| Tabletop to pedestal mounting hardware | Rust-resistant zinc-plated steel bolts, 10mm diameter, 8 connection points | |
| Surface coating | Low-VOC matte clear polyurethane finish, 0.15mm dry film thickness | |
| Floor protection pads | 5mm thick felt pads under base trim, non-scratching for hard flooring | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Central lazy Susan operation | Manual 360° smooth rotation with no locked positions, designed for shared dish access | |
|---|---|---|
| Assembly configuration | Knock-down construction, pedestal attaches to tabletop with included hardware, no permanent on-site joinery required | |
| Fixed height design | Non-adjustable 770mm dining height, compatible with standard 450mm seat height dining chairs | |
| Surface maintenance requirement | Clean with soft damp cloth, avoid abrasive cleaners and direct hot pan contact to preserve finish | |
| Non-extendable fixed top | Solid fixed round tabletop with no expansion leaves or foldable sections for consistent circular footprint | |
| Pedestal support design | Single central cylindrical column support, no protruding legs to interfere with chair placement around full perimeter | |
| Weight distribution | Centered base design evenly distributes tabletop load to prevent tipping when loaded on one side | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining room use | Ideal for 8-person family meals and dinner parties in dedicated dining spaces | |
|---|---|---|
| Private restaurant dining room use | Suitable for private VIP dining rooms in Chinese cuisine restaurants | |
| Hotel banquet suite use | Appropriate for small event dining and guest reception in hotel hospitality suites | |
| Recommended pairing | Pair with 8 matching New Chinese style solid wood dining chairs with 450mm seat height | |
| Flooring suitability | Safe for marble, wood, tile and carpet flooring with included felt floor protection pads | |
| Space requirement recommendation | Install in rooms with minimum 3000 x 3000 mm clear floor area to allow chair pull-out and circulation |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables, applicable for structural performance requirements | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for surface resistance to dry heat, applicable for finish heat resistance verification | |
| EN 71-3:2019 | Safety of toys - Migration of certain elements, applicable for coating heavy metal content limits for indoor furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural stability and dimension tolerances | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture, applicable for formaldehyde emission limits | |
| GB/T 4893.4-2013 | Surface film hardness test for furniture finishes, applicable for verifying scratch resistance of wood coating | |
| GB/T 10357.1-2013 | Mechanical test for tables - strength and stability, applicable for static load and tipping resistance verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural stability and dimension tolerances; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture, applicable for formaldehyde emission limits; 3. GB/T 4893.4-2013: Surface film hardness test for furniture finishes, applicable for verifying scratch resistance of wood coating; 4. GB/T 10357.1-2013: Mechanical test for tables - strength and stability, applicable for static load and tipping resistance verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
