Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 1800 x 780 mm | |
|---|---|---|
| Central lazy susan diameter | 900 mm | |
| Tabletop thickness | 50 mm | |
| Pedestal base diameter | 1200 mm | |
| Pedestal plinth height | 80 mm | |
| Lazy susan wood trim width | 80 mm | |
| Table edge overhang | 50 mm | |
| Lazy susan surface height above tabletop | 20 mm | |
| Under-table knee clearance height | 680 mm | |
| Pedestal vertical accent inlay width | 8 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed tabletop static load | 260 kg | |
|---|---|---|
| Lazy susan static load capacity | 50 kg | |
| Recommended seating capacity | 10 people | |
| Table net weight | 150 kg | |
| Lazy susan bearing cycle life | 100000 rotations | |
| Surface finish abrasion resistance | 2000 cycles | |
| Structure warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main tabletop | Segmented solid hardwood panels with framed inlay design | |
|---|---|---|
| Lazy susan top surface | Polished natural white marble with grey veining | |
| Lazy susan border | Solid hardwood edge trim matching table finish | |
| Pedestal base | Solid hardwood cylindrical construction with vertical veneer grain | |
| Base plinth | Layered solid hardwood stepped rounded foot | |
| Lazy susan rotation mechanism | 304 stainless steel ball bearing track with PE wear ring | |
| Surface finish | Matte brown polyurethane lacquer | |
| Assembly hardware | Zinc-plated steel connecting bolts | |
| Decorative inlays | Light-colored solid wood accent strips | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Lazy susan rotation | 360-degree manual rotation with smooth damping | |
|---|---|---|
| Assembly structure | Two-piece split construction (tabletop + pedestal base) | |
| Anti-warp tabletop design | Rear-side grooved solid wood panels | |
| Surface maintenance | Wipe-clean lacquer finish | |
| Floor protection | Felt padding under base plinth | |
| Seating compatibility | Accommodates standard dining chairs with 450mm seat height | |
| Lazy susan alignment | Centered fixed rotation axis | |
| Finish durability | UV-stable brown stain | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential formal dining room | Serves 10 guests for family meals and holiday gatherings | |
|---|---|---|
| Private restaurant dining rooms | Suitable for Chinese cuisine shared-serving style | |
| Hotel banquet private rooms | Matches traditional carved dining chair sets visible in background | |
| Tea house and club dining areas | Warm solid wood finish complements traditional Chinese decor | |
| Villa great room dining zones | Wide pedestal base provides stable, leg-free seating around full perimeter |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for surface resistance to cold liquids |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural safety | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture | |
| GB/T 4893.8-2013 | Test for surface wear resistance of furniture finishes |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural safety; 2. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture; 3. GB/T 4893.8-2013: Test for surface wear resistance of furniture finishes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
