Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 680 x 850 x 1150 mm | |
|---|---|---|
| Seat height from floor | 450 mm | |
| Seat width | 520 mm | |
| Seat depth | 480 mm | |
| Backrest height | 700 mm | |
| Headrest dimensions | 320 x 200 x 80 mm | |
| Armrest height from seat | 220 mm | |
| IV pole height from floor | 1800 mm | |
| IV hook quantity | 2 hooks | |
| Leg spread width (base) | 650 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net product weight | 28 kg | |
|---|---|---|
| Maximum static user weight capacity | 150 kg | |
| Backrest static load capacity | 80 kg | |
| IV pole maximum vertical load | 10 kg | |
| Recline mechanism cycle life | 12000 cycles | |
| Floor glide static friction coefficient | 0.6 | |
| Upholstery abrasion resistance | 50000 double rubs | |
| Frame corrosion resistance | 1000 hours | |
| Upholstery fluid repellency rating | 4 grade | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Primary frame construction | 25mm diameter chrome-plated cold-rolled steel tube, 1.5mm wall thickness | |
|---|---|---|
| Seat, back and headrest padding | 40mm high-resilience polyurethane foam, 40kg/m3 density | |
| Upholstery fabric | Medical-grade green polyester fabric, anti-bacterial, fluid-repellent finish | |
| Armrests | Bent steel support frame with dark wood-grain laminated composite arm pads | |
| IV pole construction | 19mm diameter chrome-plated steel tube, height-adjustable with 2 chrome-plated steel hooks | |
| Recline adjustment hardware | Black powder-coated steel locking hinge mechanism with manual release lever | |
| Floor contact glides | 30mm diameter non-marking black rubber fixed glides | |
| Underseat support panel | Perforated steel support mesh under seat cushion | |
| Seam construction | Stitched upholstery seams, 8 stitches per inch seam pitch | |
| Frame finish | Triple-layer polished chrome plating with corrosion-resistant clear topcoat | |
| Primary structural frame | 25 mm diameter chrome-plated cold-rolled steel tube, 1.5 mm wall thickness | |
| Armrest assemblies | 12 mm bent chrome-plated steel support frames with dark wood-grain laminated composite arm pads, 2 mm edge banding |
Adjustment / rotation / tilt / mobility / storage features
| Backrest recline adjustment | Manual ratchet locking mechanism, 4 locking positions between 95 degrees upright and 160 degrees full recline, release via under-seat lever | |
|---|---|---|
| IV pole height adjustment | Tool-less height adjustment via side-mounted locking knob, 600mm vertical travel to accommodate different fluid bag heights | |
| Fixed stable base | Four-point fixed leg design with rubber glides, no casters to prevent unwanted movement during infusion treatment | |
| Fixed position armrests | Rigid curved armrests positioned to support patient arms during IV access and extended seating, no flip or height adjustment | |
| Integrated head support | Fixed padded headrest positioned to support neck and head in both upright and reclined positions | |
| Easy-clean surface design | Smooth chrome frame and non-porous upholstery allow disinfection between patient uses | |
| Dual IV bag support | Two curved hooks at top of IV pole support hanging of standard IV fluid bags or infusion pump accessories | |
| Corrosion-resistant construction | All metal components use chrome plating suitable for regular clinical disinfection wipe-down | |
| Reclined overall depth | 1200 mm | |
| Backrest recline angle range | 110 degrees | |
| Static stable base support | Four-point splayed fixed leg design with rubber glides, no casters to prevent unwanted movement during IV cannulation and treatment | |
| Fixed forearm support armrests | Rigid triangulated wire-frame armrests positioned to support full patient forearms during IV access and extended seating, no flip-up or height adjustment capability |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 unit | |
|---|---|---|
| Shipping carton dimensions | 820 x 680 x 900 mm | |
| Gross shipping weight | 32 kg | |
| Shipping volume per unit | 0.5 CBM | |
| Assembly time on site | 15 minutes | |
| 20ft GP container loading quantity | 52 units | |
| 40ft HQ container loading quantity | 124 units | |
| Packaging materials | 5-layer corrugated carton, EPS foam edge protection, polyethylene film wrap | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Hospital outpatient infusion centers | Designed for extended patient seating during intravenous therapy, with recline function and integrated IV pole for clinical workflow efficiency | |
|---|---|---|
| Clinic treatment rooms | Suitable for minor procedure and observation use, with stable fixed base and easy-clean surfaces for repeated patient use | |
| Blood donation centers | Adjustable recline position supports donor comfort during phlebotomy and post-donation recovery periods | |
| Community health service centers | Durable construction and compact footprint suit high-volume public primary care settings | |
| Post-operative recovery wards | Reclining position and padded support accommodate patients requiring short-duration seated recovery after procedures | |
| Dialysis center waiting and treatment zones | Durable fabric and load-rated frame support extended seating sessions for outpatient dialysis care | |
| Configuration recommendation | Place at 1200mm minimum spacing between adjacent chairs to allow clinical staff access to patients from all sides during IV administration | |
| General practice clinic treatment rooms | Suitable for minor procedure use and short-term patient observation, with stable fixed base and disinfection-compatible surfaces for high patient turn-over |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Applicable European standard for non-domestic seating strength, durability and safety, recommended for structural load testing | |
|---|---|---|
| EN 13722:2004 | Applicable standard for furniture seating test methods for stability, recommended for verification of fixed leg stability in all recline positions |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3328-2016 | Applicable standard for metal furniture general technical requirements, recommended for frame strength and finish quality inspection | |
|---|---|---|
| GB 28007-2011 | Applicable standard for children's and institutional furniture safety, recommended for edge rounding and structural safety verification for clinical use | |
| GB/T 19001-2016 | Applicable quality management system standard for medical furniture supply chain consistency | |
| GB/T 16799-2008 | Furniture upholstery fabric performance standards, recommended for abrasion resistance and color fastness verification for clinical cleaning protocols |
This product must meet the following technical requirements: 1. GB/T 3328-2016: Applicable standard for metal furniture general technical requirements, recommended for frame strength and finish quality inspection; 2. GB 28007-2011: Applicable standard for children's and institutional furniture safety, recommended for edge rounding and structural safety verification for clinical use; 3. GB/T 19001-2016: Applicable quality management system standard for medical furniture supply chain consistency; 4. GB/T 16799-2008: Furniture upholstery fabric performance standards, recommended for abrasion resistance and color fastness verification for clinical cleaning protocols; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
