Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1750 x 650 x 800 mm | |
|---|---|---|
| Single seat width | 520 mm | |
| Single seat depth | 480 mm | |
| Seat height from floor | 430 mm | |
| Backrest height per seat | 420 mm | |
| Armrest height from seat surface | 220 mm | |
| Leg spread width | 1650 mm | |
| Ground clearance under seat | 280 mm | |
| Armrest width | 50 mm | |
| Frame beam cross-section | 60 x 30 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total product net weight | 28 kg | |
|---|---|---|
| Static load per seat | 150 kg | |
| Total static load for full unit | 450 kg | |
| Recommended maximum user weight per seat | 120 kg | |
| Seat cushion compression recovery | 95% | |
| Floor foot static friction coefficient | 0.6 | |
| Daily occupancy capacity | 200 users | |
| Warranty period for structural frame | 5 years | |
| Warranty period for upholstery and wearing parts | 2 years | |
| Structural frame durability cycle rating | 100000 seat load cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Support frame main beam | 1.5mm thick cold-rolled steel with matte silver powder coating | |
|---|---|---|
| Leg supports | Cast aluminum alloy with brushed silver finish | |
| Armrests | Die-cast aluminum alloy with smooth polished surface treatment | |
| Seat base panels | 1.2mm thick cold-rolled steel perforated support plates | |
| Seat and back cushion cores | 40mm thick high-resilience polyurethane foam, density 45kg/m³ | |
| Seat and back upholstery | 0.8mm thick polyurethane (PU) leather, abrasion resistance 50000 Martindale cycles | |
| Floor contact pads | Non-marking nitrile rubber | |
| Connection hardware | Grade 8.8 zinc-plated steel bolts and brackets | |
| Stitching details | Reinforced polyester thread with 8 stitches per inch seam pitch | |
| Back support inner panel | 1.0mm thick cold-rolled steel backing plate | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Fixed gang seating configuration | Three individually separated seat bays with intermediate armrests, prevents unintended shared seating and delineates personal space for waiting users | |
|---|---|---|
| Fixed upright back support | 105 degree fixed backrest angle, provides upright support without recline mechanism, suitable for high-traffic areas where adjustable parts could be damaged | |
| Non-reclining seat structure | Fixed 5 degree forward seat tilt, reduces forward sliding when seated and supports upright posture for short waiting periods | |
| Surface cleaning access | Smooth non-porous PU upholstery allows wipe-down cleaning with common disinfectants, no fabric seams that trap debris on seat contact surfaces | |
| Floor stability design | Four-point curved leg base with rubber contact pads eliminates rocking on uneven floors, no wall anchoring required for standard installation | |
| Modular connection capability | End frame brackets allow ganging multiple 3-seat units together in continuous rows for large waiting areas, no additional adapters required for straight row installations | |
| No moving adjustment parts | No tilt, swivel, or height adjustment mechanisms, reduces maintenance requirements and vandalism risk in unsupervised public spaces | |
| Lower under-seat clearance | Open space under seats allows full access for brooms, mops and robotic vacuums without moving the bench | |
| Fixed seat tilt structure | 5 degree fixed forward seat tilt, reduces forward sliding when seated and supports neutral upright posture for short waiting periods | |
| Disinfectable surface design | Smooth non-porous PU upholstery allows wipe-down cleaning with 75% alcohol and common quaternary ammonium disinfectants, no deep fabric crevices that trap debris on seat contact surfaces | |
| Modular ganging capability | End frame pre-drilled brackets allow connecting multiple 3-seat units together in continuous straight rows for large waiting areas, no additional adapter parts required | |
| Maintenance-free fixed construction | No tilt, swivel, height adjustment or moving mechanical parts, reduces routine maintenance requirements and vandalism risk in unsupervised public spaces |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 carton | |
|---|---|---|
| Shipping carton dimensions | 1780 x 680 x 420 mm | |
| Gross shipping weight | 32 kg | |
| Shipping volume per unit | 0.51 CBM | |
| Required assembly time | 30 minutes | |
| 20ft GP container loading capacity | 52 units | |
| 40ft HQ container loading capacity | 126 units | |
| Packaging materials | 5-layer corrugated carton with EPS foam corner protection, plastic shrink wrap for cushion sets, sealed polybag for hardware and instructions | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Hospital clinic waiting areas | Suitable for patient and visitor waiting zones, with disinfectable PU upholstery that supports regular sanitization between users, durable frame withstands continuous daily use | |
|---|---|---|
| Public transport terminals | Ideal for airport, railway and bus station waiting concourses, fixed heavy-duty structure resists heavy use and impact, intermediate armrests organize passenger seating | |
| Government service hall waiting zones | Appropriate for civic service, bank and public administrative office waiting areas, teal neutral finish fits formal public interior schemes, low maintenance design reduces operational upkeep | |
| Corporate reception and break areas | Can be deployed in office reception lobbies and employee break zones, comfortable padded cushions provide short-term seating for visitors and staff, clean simple design complements modern office interiors | |
| Educational institution common areas | Suitable for school administration lobbies, library study zones and student service waiting areas, sturdy construction resists heavy student use, rounded edge design reduces injury risk | |
| Indoor installation only | Designed for fully sheltered indoor use, powder coated frame and PU upholstery are not rated for long-term outdoor exposure to rain or direct UV radiation | |
| Recommended complementary configuration | Pair with matching single-seat and corner units to create custom waiting zone layouts, install with spaced 1200mm access aisles between rows for wheelchair and pedestrian traffic | |
| Recommended layout configuration | Pair with matching single-seat units and corner connectors to create custom waiting zone layouts, install rows with 1200mm clear access aisles between seat fronts for wheelchair access and pedestrian traffic |
EU Market Access Requirements* EN Standards
| EN 16139:2013 Furniture - Strength, durability and safety - Requirements for non-domestic seating | Applicable European standard for structural safety, stability and durability of commercial public seating excluding office work chairs | |
|---|---|---|
| EN 1022:2018 Furniture - Seating - Determination of stability | Reference test method for verifying stability of fixed multi-seat benches to prevent tipping when users apply load to seat edges | |
| EN 14465:2003 Textiles - Upholstery fabrics - Specification and test methods | Applicable performance standard for abrasion resistance, color fastness and seam strength of upholstery materials used on public seating |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for furniture | Applicable standard for dimensional tolerances, surface finish quality and structural stability requirements for fixed metal-framed seating used in general public spaces | |
|---|---|---|
| GB/T 10357.3-2013 Test of mechanical properties of furniture - Strength and durability of chairs and stools | Recommended test standard for seat static load, backrest load and leg strength verification for commercial public seating products | |
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applicable for formaldehyde and harmful substance limits for any composite panel components included in seat backing structures | |
| GB/T 24821-2009 Public seating for airport terminals | Reference performance standard for high-traffic public seating durability, load requirements and surface finish performance, suitable for hospital, station and terminal applications |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for furniture: Applicable standard for dimensional tolerances, surface finish quality and structural stability requirements for fixed metal-framed seating used in general public spaces; 2. GB/T 10357.3-2013 Test of mechanical properties of furniture - Strength and durability of chairs and stools: Recommended test standard for seat static load, backrest load and leg strength verification for commercial public seating products; 3. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applicable for formaldehyde and harmful substance limits for any composite panel components included in seat backing structures; 4. GB/T 24821-2009 Public seating for airport terminals: Reference performance standard for high-traffic public seating durability, load requirements and surface finish performance, suitable for hospital, station and terminal applications; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
