Name: Mid-Back Mesh Office Task Chair with Orange Fabric Seat
Brand: GUOYOU
SKU: WYXMCP

Time

Field

Original Value

Corrected Value

Note / Status

No correction records yet. Found an error? Click the flag at the end of a row to report it.

PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	620 × 600 × 1050 mm
Seat width	500 mm
Seat depth	480 mm
Seat height range	540 mm
Backrest height	520 mm
Backrest width	460 mm
Armrest height from seat	220 mm
Chrome base diameter	640 mm
Caster diameter	50 mm
Seat height maximum	540 mm
Armrest pad length	260 mm
Chrome 5-star base diameter	640 mm
Gas lift outer tube diameter	50 mm
Seat cushion thickness	80 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Net weight	14 kg
Recommended static load capacity	120 kg
Gas lift stroke	100 mm
Backrest tilt angle range	12 degrees
Caster rolling durability	100000 cycles
Armrest static load per side	80 kg
Backrest maximum tilt angle	12 degrees
Seat foam density	45 kg/m³
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest frame	Black plastic frame with rigid internal support
Backrest surface	Grey breathable woven mesh stretched over frame
Seat cushion	Orange woven fabric upholstery over polyurethane foam
Armrest assembly	Black nylon arm pads mounted on chrome-plated steel supports
Base structure	Chrome-plated steel 5-star base with polished finish
Height adjustment	Black-coated gas lift cylinder with chrome outer tube
Casters	Black dual-wheel casters with soft tread
Control mechanism	Steel tilt mechanism under seat with plastic adjustment levers
Seat cushion core	High-density molded polyurethane foam with shaped contour
Seat upholstery	Orange woven polyester fabric stitched over foam cushion with locked seams
Seat inner frame	Plywood inner support panel with steel reinforcement brackets
Height adjustment gas lift	Black-coated internal gas cylinder with chrome-plated steel outer tube

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seat height adjustment	Pneumatic height adjustment via right-side lever with 100 mm total stroke
Backrest tilt	Synchronous tilt mechanism with lockable recline up to 12 degrees from upright
360-degree swivel	Full 360-degree rotation around central gas lift column
Mobile base	Five dual-wheel casters for smooth movement on hard and carpeted floors
Fixed armrests	Fixed-position armrests with horizontal pads for forearm support
Breathable back support	Tensioned mesh back provides passive lumbar ventilation and flexible support
Fixed armrest support	Fixed-position armrests with 260 mm long horizontal pads for forearm rest
Tilt tension adjustment	Rotary tension knob under seat adjusts backrest recline resistance for different user weights
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Packaging units	1 unit per carton
Carton dimensions	650 x 620 x 350 mm
Gross weight per carton	16 kg
Volume per carton	0.142 CBM
20 ft container load	280 units
20 ft container load quantity	280 units
Assembly time per unit	20 minutes
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office	Suitable for daily workstation use in open office environments due to breathable mesh back and compact mid-back design
Meeting rooms	Appropriate for conference and meeting room seating where fixed-arm task chairs with swivel function are required
Home office	Works well for home office setups with standard-height desks and limited floor space
Staff workstations	Designed for 8-hour daily sedentary use by office personnel at standard 760 mm height desks
Training areas	Suitable for training rooms where mobile, stackable or easily reconfigurable task seating is needed
Open-plan office workstations	Suitable for 8-hour daily workstation use in open office environments due to breathable mesh back and compact mid-back design
Staff administrative workstations	Designed for daily sedentary use by administrative and clerical personnel at standard 760 mm height desks
Training room seating	Suitable for training rooms where mobile, easily reconfigurable task seating is needed for frequent layout adjustments

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 1335-1:2020	Applicable for office chair dimensions and safety requirements
EN 1335-2:2020	Applicable for office chair strength, durability and stability testing

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.1-2017	Applicable for general-purpose office chairs performance and durability testing

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3326-2016	Applicable for furniture dimensions and ergonomic requirements of office chairs
GB/T 10357.3-2013	Applicable for chair stability and strength testing methods
GB 18584-2001	Applicable for formaldehyde emission limits for wood-based parts and upholstery materials

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3326-2016: Applicable for furniture dimensions and ergonomic requirements of office chairs;
2. GB/T 10357.3-2013: Applicable for chair stability and strength testing methods;
3. GB 18584-2001: Applicable for formaldehyde emission limits for wood-based parts and upholstery materials;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · OC-MB-001

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · OC-MB-001

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · OC-MB-001Open Export Tool

Quick Actions

Post an RFQ

Product Description

The GUOYOU OC-MB-001 Mid-Back Mesh Office Task Chair features a sleek, balanced silhouette defined by its two-tone color scheme and compact mid-back profile. Its layout centers on a tensioned grey woven mesh backrest framed in black plastic, paired with a vibrant orange fabric seat cushion that creates a striking visual contrast. Fixed armrests with black horizontal pads sit symmetrically on either side of the seat, anchored by a polished chrome-plated steel 5-star base fitted with black dual-wheel casters. The overall structure presents a clean, functional aesthetic tailored for everyday work environments. Constructed with durable, performance-focused materials, the chair’s backrest uses breathable woven mesh stretched over a black plastic frame with rigid internal support, delivering flexible support and passive lumbar ventilation. The seat cushion combines orange woven polyester upholstery with locked seams over a high-density molded polyurethane foam core with a shaped contour, supported by a plywood inner panel with steel reinforcement brackets. Its armrest assembly pairs black nylon pads with chrome-plated steel supports, while the height adjustment system uses a black-coated gas lift cylinder with a chrome outer tube. A steel tilt mechanism under the seat, controlled by plastic adjustment levers, connects the seat to the 5-star base, which is fitted with soft-tread dual-wheel casters for smooth mobility. Functionally, the chair offers pneumatic seat height adjustment via a right-side lever, with a total vertical stroke of 100 mm. Its synchronous tilt mechanism supports lockable recline up to 12 degrees from the upright position, with a rotary tension knob under the seat to adjust recline resistance. It provides full 360-degree swivel rotation around the central gas lift column, and the five dual-wheel casters enable multidirectional movement across different floor surfaces. Fixed-position armrests with long horizontal pads offer stable forearm support, and the mesh back delivers consistent, breathable support for prolonged seated use. This chair is suited for a range of commercial and residential spaces. In commercial settings, it fits open-plan office workstations, staff administrative desks, meeting rooms, and training areas, where its mobile design supports frequent layout reconfiguration and 8-hour dly use. For residential applications, it works well in home offices with standard-height desks and limited floor space, delivering reliable functionality without excessive footprint. For procurement planning, the chair has a net weight of 14 kg, with a recommended static load capacity of 120 kg to guide user suitability. It ships one unit per carton, with single-person assembly required. Teams should confirm material specifications including fabric abrasion ratings, gas lift certification, and base corrosion resistance directly with the supplier, as these details require official validation to align with specific project requirements.

Mid-Back Mesh Office Task Chair with Orange Fabric Seat Specifications
