PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源：工厂资料结构化字段，最终以实测值为准

产品外部尺寸（宽 × 深 × 高）	680 × 650 × 1010 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源：产品性能数据，采购前请核对具体测试口径

Net weight	14 kg
Recommended user weight	120 kg
Static seat load verification target	600 kg
Back static load verification target	136 kg
Upholstery abrasion acceptance target	50,000 Martindale cycles
Swivel rotation	360 degrees
Gas-lift height travel	80 mm
Seating capacity	1 person
Foam density target	45 kg/m3
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%

PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源：以工厂材质清单与验货报告为准

Outer seat and back upholstery	Light beige smooth-faced upholstery with angular chevron stitching
Seat cushion	80 mm polyurethane foam pad over a load-bearing seat plate
Back padding	Molded polyurethane foam in an ergonomic wraparound shell
Internal seat support	12 mm plywood or steel composite seat carrier
Four-star base	Polished die-cast aluminum or chrome-plated steel base
Base arm section	35 x 20 mm polished metal profile
Center column	Black telescoping sleeve with chrome gas-lift tube
Gas lift	50 mm diameter class 3 steel gas lift
Adjustment lever	Black polymer paddle lever mounted under the seat
Floor contacts	Four non-marking polymer glide pads
Edge trim	Dark perimeter piping or welt along the upholstered shell
Seam construction	Stitched angular panel seams with 6 mm stitch pitch target

PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源：功能配置参数，以供应商正式规格为准

Seat height adjustment	Paddle lever controls the gas lift through an 80 mm travel between 440 and 520 mm seat height
360-degree swivel	Central column allows the seat shell to rotate fully while the four-star base remains stationary
Integrated body support	Backrest and arms form one continuous wraparound shell for lateral elbow and back support
Stationary floor placement	Four glide feet provide a non-rolling footprint for meeting and visitor areas
Lumbar contour	Chevron-shaped back split provides a shaped lower-back zone without a separate adjustable lumbar part
Posture type	Fixed upright executive posture with no visible recline handle or tilt tension knob
Armless-gap entry	Open front between the integrated arm wings allows side access while retaining wraparound support
Height mechanism retention	Gas lift locks at the selected height when the paddle lever is released
Floor protection	Four polymer glides distribute load and reduce scratching on hard flooring
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源：外贸报价与装柜测算参考

Carton dimensions	760 x 680 x 420 mm
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源：依据产品结构与品类整理的推荐应用场景

Executive office visitor seating	Stationary swivel design suits guests in front of executive desks while maintaining a formal appearance
Meeting room	Single 680 mm-wide chair fits conference tables and supports short-to-medium seated sessions
Reception and lounge area	Beige upholstery and polished base provide a refined guest seat in hotel or corporate lounges
Manager workstation	Height-adjustable seat allows use at desks from 720 to 760 mm high
Consultation room	Swivel access and wraparound arm support suit interviews, advisory meetings, and client discussions
Hard-floor installation	Glide feet are appropriate for wood, tile, vinyl, and polished stone floors where casters are not required
Color coordination	One visible light beige upholstery color with black and polished-metal contrast elements
Recommended Matching Desk Size	2.4 m executive desk

STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 16139	Strength, durability, and safety standard for non-domestic seating, suitable for visitor and office chair acceptance
EN 1022	Determination of stability for seating, applicable to the tall four-star base and elevated seating positions
EN 1335-2	Safety requirements for office work chairs, applicable where this model is used at office desks

STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.4	Safety and performance reference for lounge and public-office seating with static, load, and stability tests
ANSI/BIFMA X5.1	General office-chair safety and performance tests may be specified for heavier commercial use

STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 10357.2	Test method for furniture surface physical and chemical properties, applicable to upholstery and exposed finish acceptance
GB/T 10357.3	Test method for furniture strength and durability, applicable to seat, back, arm, and base verification
GB 17927	Safety requirements for upholstered furniture, applicable to structural and fire-safety procurement checks in China

招标文件标准化描述文本

本产品须满足以下技术参数要求：
1. GB/T 10357.2：Test method for furniture surface physical and chemical properties, applicable to upholstery and exposed finish acceptance；
2. GB/T 10357.3：Test method for furniture strength and durability, applicable to seat, back, arm, and base verification；
3. GB 17927：Safety requirements for upholstered furniture, applicable to structural and fire-safety procurement checks in China；
最终交付参数、检测报告和验收标准以双方采购合同为准。

GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告，可选择公制或英制单位。

PDF · SWV-4STAR-BGE-01

完整参数 Excel

导出全部商品信息与参数模块，文件内容统一使用英文。

XLSX · SWV-4STAR-BGE-01

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段，可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · SWV-4STAR-BGE-01打开导出工具

页面快速操作

发布采购询价

产品描述

The Swivel Upholstered Executive Visitor Chair, model SWV-4STAR-BGE-01, is an unbranded contemporary guest and meeting chair with a structured, executive appearance. Its light beige smooth-faced upholstery covers a padded seat and a wraparound back shell, while angular chevron stitching and a shaped back split give the chair a defined visual character. The back and integrated arms form a continuous enclosure that supports the lateral back and elbows, with an open front between the arm wings allowing convenient side access. A polished four-star metal base, black center column, chrome gas-lift sleeve, and visible black adjustment lever complete the refined contrast between soft upholstery and metallic support. The chair is built with a padded polyurethane seat cushion over a load-bearing seat plate and an internal plywood or steel composite carrier. The back uses molded polyurethane foam within an ergonomic wraparound shell, providing a fixed lower-back contour without a separate adjustable lumbar mechanism. Its base is offered in polished die-cast aluminum or chrome-plated steel with a polished metal profile and four glide feet. The class 3 steel gas lift has a chrome tube and is controlled by a black polymer paddle lever beneath the seat. Functionally, the seat adjusts through 80 mm of height travel, from 440 to 520 mm, and rotates 360 degrees while the four-star base remains stationary. The glides create a non-rolling footprint suited to formal visitor settings, and the fixed upright posture keeps the presentation clean, with no visible recline handle or tilt tension control. The chair has an overall size of 680 x 650 x 1010 mm, a 540 mm clear width between armrests, and a net weight of 14 kg. The stated recommended user weight is 120 kg, with specified verification targets for static seat and back loading, plus a 50,000 Martindale cycle upholstery abrasion acceptance target. This model is appropriate for executive office visitor positions, conference rooms, reception areas, corporate or hotel lounges, manager workstations, and consultation or interview spaces. Its stationary glide feet suit wood, tile, vinyl, and polished stone floors where casters are not desired, and the height-adjustable seat supports desks up to 760 mm high. Procurement teams should plan for one set supplied in two cartons, with a packaged gross weight of 23 kg and a reference assembly time of 40 minutes per set. Confirm the selected base material, upholstery appearance, floor-protection requirements, delivery packaging, and assembly support before ordering for multi-room projects.

Swivel Upholstered Executive Visitor Chair Specifications
