| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1980 x 1070 x 775 mm | |
|---|---|---|
| Tabletop thickness | 48 mm | |
| Apron height from floor | 706 mm | |
| Leg section size | 80 x 80 mm | |
| Perimeter side leg opening width | 1780 mm | |
| Perimeter end leg opening width | 870 mm | |
| Tabletop overhang past apron | 152 mm | |
| Leg wall thickness (solid wood) | 80 mm | |
| Adjustable foot height adjustment range | 15 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed static tabletop load capacity | 150 kg | |
|---|---|---|
| Net product weight | 55 kg | |
| Seating capacity | 6 | |
| Tabletop surface Mohs hardness | 6 | |
| Tabletop water absorption rate | 0.2% | |
| Finish abrasion resistance cycles | 2000 | |
| Frame wood moisture content | 10% | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table legs and apron | Walnut-stained solid rubberwood with matte lacquer finish | |
|---|---|---|
| Tabletop surface | Black matte sintered stone with scratch-resistant seal | |
| Tabletop core substrate | High-density MDF backing under stone top | |
| Leg-to-apron connectors | 60 mm steel confirmat screws with pre-installed wood inserts | |
| Foot levelers | Non-marking black polypropylene adjustable pads | |
| Apron wood finish thickness | 0.15 mm | |
| Edge profile | 1 mm rounded machined edge on tabletop perimeter | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Assembly requirement | Knockdown leg attachment with included hardware | |
|---|---|---|
| Leveling adjustment | 15 mm height adjustment per foot to accommodate uneven floors | |
| Surface function | Stain, heat and scratch resistant non-porous tabletop for dining use | |
| Fixed structure | No extendable leaf or folding mechanism for permanent dining placement | |
| Weight distribution | 4-point load transfer from tabletop to floor via corner legs | |
| Edge safety | Rounded tabletop edges reduce impact injury risk | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining rooms | Seats 6 people for daily family meals and casual entertaining | |
|---|---|---|
| Open-plan kitchen dining areas | Compact profile fits combined kitchen and living spaces | |
| Small restaurant and cafe seating | Durable surface withstands high-traffic commercial food service use | |
| Apartment dining spaces | Scaled dimensions fit smaller urban residential floor plans | |
| Mid-century modern interior schemes | Walnut frame and black top match retro modern decor aesthetics |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Domestic furniture strength, durability and safety for dining tables, EU market reference | |
|---|---|---|
| EN 13722:2004 | Furniture surface resistance to cold liquids for dining table top performance | |
| EN 14749:2016 | Safety requirements for household and kitchen storage and work surfaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to domestic market supply | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limit for interior wooden furniture, applicable for indoor air quality | |
| GB/T 4893.8-2013 | Surface wear resistance test method for furniture finishes |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to domestic market supply; 2. GB 18584-2001: Formaldehyde emission limit for interior wooden furniture, applicable for indoor air quality; 3. GB/T 4893.8-2013: Surface wear resistance test method for furniture finishes; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
