| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Table overall dimensions (closed) | 1550 x 900 x 760 mm | |
|---|---|---|
| Table extended length | 2150 mm | |
| Tabletop thickness | 12 mm | |
| Table leg section | 60 x 60 mm | |
| Under-table knee clearance height | 660 mm | |
| Chair seat height | 450 mm | |
| Chair seat dimensions | 450 x 420 mm | |
| Chair backrest height | 380 mm | |
| Extension leaf width | 600 mm | |
| Apron height below tabletop | 100 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Table distributed static load capacity | 150 kg | |
|---|---|---|
| Seating capacity (closed configuration) | 6 people | |
| Seating capacity (extended configuration) | 8 people | |
| Table net weight (without chairs) | 75 kg | |
| Finish abrasion resistance (tabletop) | 4000 cycles | |
| Wood frame moisture content | 12% | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop | 12mm thick black matte sintered stone | |
|---|---|---|
| Table frame and apron | Walnut-stained solid rubberwood | |
| Table legs | Tapered solid walnut-stained wood | |
| Chair frames | Solid walnut-stained hardwood | |
| Chair seat padding | 40mm thick high-density polyurethane foam | |
| Chair seat upholstery | 0.8mm thick black PU faux leather | |
| Extension mechanism hardware | Cold-rolled steel slides | |
| Joinery connectors | Zinc-plated steel dowels and cam locks | |
| Wood finish | Matte nitrocellulose lacquer | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Table extension mechanism | Pull-out dual-leaf extension with 600mm total added length | |
|---|---|---|
| Leg positioning | Four corner-mounted tapered legs | |
| Table edge profile | Soft rounded radius edge | |
| Chair design | Armless curved backrest silhouette | |
| Tabletop surface property | Non-porous matte surface | |
| Assembly requirement | Knockdown assembly required | |
| Chair floor protection | Felt pads pre-installed on leg bases | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Total shipping gross weight | 140 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining room | Serves 6 daily, expands to 8 for family gatherings and dinner parties | |
|---|---|---|
| Open-plan kitchen dining area | Compact closed size fits small to medium apartment kitchen layouts | |
| Studio apartment dining zone | Scandinavian minimalist style coordinates with modern light wood or neutral interiors | |
| Small café dining area | Durable easy-clean surface suits light commercial casual dining use | |
| Recommended pairing | Pairs with 1200mm sideboard for tableware storage along adjacent dining wall | |
| Floor protection suitability | Felt-pad legs suitable for tile, hardwood, and laminate hard flooring surfaces |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 1022:2018 | Furniture - Seating - Determination of stability for domestic dining chairs | |
| EN 13722:2004 | Furniture - Test methods for strength and durability of chair seats and backs |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to solid wood dining set structural safety | |
|---|---|---|
| GB/T 4893.1-2021 | Furniture surface wear resistance test, applicable to tabletop finish durability validation | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances, applicable to formaldehyde emission control |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to solid wood dining set structural safety; 2. GB/T 4893.1-2021: Furniture surface wear resistance test, applicable to tabletop finish durability validation; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances, applicable to formaldehyde emission control; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
