Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 800 × 760 mm | |
|---|---|---|
| Tabletop thickness | 25 mm | |
| Under-table knee clearance height | 680 mm | |
| Leg top diameter (table attachment) | 60 mm | |
| Leg bottom diameter (floor contact) | 45 mm | |
| Apron height | 55 mm | |
| Corner radius (tabletop) | 40 mm | |
| Leg position offset from corners | 80 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop distributed static load capacity | 180 kg | |
|---|---|---|
| Product net weight | 33 kg | |
| Surface abrasion resistance (finish) | 400 cycles | |
| Wood moisture content (production standard) | 10% | |
| Maximum weight per leg static load | 70 kg | |
| Hardware joint torque resistance | 12 Nm | |
| Seating capacity per long side | 2 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop core | Kiln-dried solid natural oak wood | |
|---|---|---|
| Tabletop finish | Clear matte natural oil coating | |
| Table legs | Solid oak tapered cylindrical wood pieces | |
| Structural apron | Solid oak matching wood frame | |
| Internal bracing | Powder-coated steel transverse cross braces | |
| Assembly fasteners | Zinc-plated steel bolt and cam lock hardware | |
| Floor contact pads | Felt non-slip protective pads | |
| Finish coating thickness | 0.1 mm | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating support | Accommodates 4 diners with unobstructed leg room on all four sides | |
|---|---|---|
| Safety edge design | Soft rounded corners reduce impact injury risk | |
| Knock-down assembly | Flat-packed for transport, assembled with included hex key | |
| Surface maintenance | Oiled finish can be spot cleaned and re-oiled for long-term use | |
| Floor protection | Felt leg pads prevent scuffing on hard flooring and rugs | |
| Level adjustment | Small adjustable glides compensate for minor uneven floor surfaces | |
| Stability design | Wide leg stance resists tipping when loaded with tableware and meals | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining rooms | Fits compact 4-person households with 1200mm length for small dining spaces | |
|---|---|---|
| Apartment kitchen nooks | Scaled appropriately for limited-space open-plan kitchen dining areas | |
| Casual home breakfast areas | Standard dining height suitable for daily meals and casual dining use | |
| Small office break rooms | Neutral light wood finish fits modern office pantry break areas for 4 staff | |
| Studio living spaces | Minimalist Nordic design complements light, neutral small-space interiors | |
| Vacation rental dining areas | Durable solid wood construction suitable for short-term rental frequent use |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic dining tables, applicable for performance verification | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for surface finishes of furniture, applicable for finish durability testing |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural checks | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials – limit of harmful substances in wooden furniture, applicable for formaldehyde testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural checks; 2. GB 18584-2001: Indoor decorating and refurbishing materials – limit of harmful substances in wooden furniture, applicable for formaldehyde testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
