Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1600 x 900 x 750 mm | |
|---|---|---|
| tabletop thickness | 12 mm | |
| leg cross section | 60 x 60 mm | |
| apron height | 100 mm | |
| knee clearance height | 650 mm | |
| corner radius | 15 mm | |
| perimeter leg inset | 100 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| distributed static tabletop load | 150 kg | |
|---|---|---|
| tabletop stain resistance grade | 5 | |
| tabletop Mohs hardness | 6 | |
| frame moisture content | 12% | |
| residential warranty period | 3 years | |
| seating capacity | 6 diners | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| tabletop surface | 12mm matte white sintered stone | |
|---|---|---|
| support apron | Solid light natural ash wood | |
| table legs | Solid square rubberwood/ash blanks with rounded edges | |
| tabletop substrate | High-density moisture-resistant MDF core | |
| connecting hardware | Zinc-plated steel cam locks and bolts | |
| surface finish on wood | Clear matte water-based lacquer | |
| foot pads | Non-slip PE plastic levelers | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| structure type | Fixed non-extendable rectangular table | |
|---|---|---|
| seating access | Full 360-degree perimeter knee clearance | |
| surface resistance | Stain, heat, scratch and water resistant tabletop | |
| assembly method | Knock-down flat-pack assembly | |
| leveling adjustment | Minor height adjustment via foot pads | |
| edge design | Soft rounded radius edges on all corners | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| residential dining room | Fits 6-person family meals in small to medium apartment dining spaces | |
|---|---|---|
| open plan kitchen dining area | Complements light-toned Scandinavian, minimalist or Japandi interior schemes | |
| small restaurant cafe seating | Suitable for casual dining venues with 6-guest table configurations | |
| breakfast nook placement | Fits in open kitchen nooks adjacent to kitchen cabinetry | |
| matching set configuration | Pairs with armless upholstered light wood dining chairs of matching style |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture, strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Furniture test methods for table stability and static load |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood frame dining tables | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of formaldehyde emission for wooden furniture | |
| GB/T 4893.4-2013 | Surface wear resistance test method for furniture surfaces |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood frame dining tables; 2. GB 18584-2001: Indoor decoration material limit of formaldehyde emission for wooden furniture; 3. GB/T 4893.4-2013: Surface wear resistance test method for furniture surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
