| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (table, closed) | 1520 x 950 x 750 mm | |
|---|---|---|
| Under-table knee clearance height | 640 mm | |
| Table leg cross-section | 40 x 40 mm square solid wood | |
| Individual chair dimensions | 460 x 550 x 940 mm | |
| Chair seat height from floor | 460 mm | |
| Chair seat usable area | 420 x 400 mm | |
| Chair backrest height above seat | 480 mm | |
| Extension leaf individual width | 355 mm | |
| Tabletop panel thickness | 25 mm | |
| Chair leg cross-section | 28 x 28 mm square solid wood | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set net weight | 76 kg | |
|---|---|---|
| Tabletop static distributed load capacity | 75 kg | |
| Single chair rated user weight capacity | 110 kg | |
| Seating capacity (table closed) | 4 persons | |
| Seating capacity (table fully extended) | 6 persons | |
| Surface finish abrasion resistance | 400 cycles | |
| Fastener torque check interval | 14 days | |
| Recommended floor protection pad thickness | 3 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table main frame and legs | Solid natural hardwood with clear matte acrylic lacquer finish | |
|---|---|---|
| Tabletop panel | Edge-glued solid hardwood planks with rounded safety corners | |
| Extension leaf panels | Matching edge-glued solid hardwood with integrated sliding rail hardware | |
| Chair frames and legs | Solid natural hardwood with cross-stretcher bracing for stability | |
| Chair backrest spindles and top rail | Solid turned hardwood spindles with curved shaped top rail | |
| Chair seat panels | Shaped solid hardwood panels with rounded front edge | |
| Extension rail hardware | Powder-coated cold-rolled steel sliding tracks with positive locking stops | |
| Surface finish | Low-VOC clear acrylic lacquer with light natural wood tone | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Table extension mechanism | Dual pull-out integrated leaves with self-locking rails, no separate storage required | |
|---|---|---|
| Extension operation | Two-person operation to pull table halves apart and deploy leaves to lock position | |
| Chair stability bracing | Full perimeter cross-stretchers between chair legs prevent racking under load | |
| Floor protection compatibility | Pre-drilled leg bases accept 3mm felt floor protectors to prevent surface scratches | |
| Cleaning and maintenance | Wipe clean with mild soapy cloth, dry immediately, avoid prolonged liquid contact | |
| Knock-down assembly | Flat-pack design requires adult assembly with included hex key hardware | |
| Seating ergonomics | Curved seat pan and angled spindle back support upright dining posture for 2+ hour meals | |
| Extension support | Integrated leg supports maintain tabletop flatness at full extended length without separate removable legs | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential dining rooms | Ideal for 4-person daily meals, expands to seat 6 for family gatherings or small dinner parties | |
|---|---|---|
| Small apartment open-plan spaces | 1520mm closed length fits compact dining nooks adjacent to kitchens or living areas | |
| Scandinavian or minimalist interiors | Light natural wood finish and spindle-back design coordinate with neutral, Japandi or Nordic decor schemes | |
| Rental property furnishing | Durable solid wood construction and flat-pack design suit long-term residential rental installations | |
| Casual breakfast areas | Standard 750mm height pairs with standard dining seating for daily breakfast and casual work use | |
| Indoor dry environments only | Lacquered wood construction is not suitable for outdoor or high-moisture bathroom spaces | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture seating strength, durability and safety requirements, applicable to included dining chairs | |
|---|---|---|
| EN 1022:2018 | Domestic furniture seating stability test methods, applicable to chair anti-tipping verification | |
| EN 15372:2016 | Domestic furniture tables strength, durability and safety requirements, applicable to dining table load testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to domestic dining table and chair strength and stability | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture, formaldehyde emission ≤1.5mg/L | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to tabletop static load and leg strength testing | |
| GB/T 10357.3-2013 | Furniture mechanical performance test for chairs, applicable to seat and back static/dynamic load testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to domestic dining table and chair strength and stability; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture, formaldehyde emission ≤1.5mg/L; 3. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to tabletop static load and leg strength testing; 4. GB/T 10357.3-2013: Furniture mechanical performance test for chairs, applicable to seat and back static/dynamic load testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
