Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1350 × 1350 × 775 mm | |
|---|---|---|
| Extended table dimensions (oval) | 1800 x 1350 mm | |
| Tabletop thickness | 51 mm | |
| Leg cross-section dimensions | 60 x 60 mm | |
| Under-table knee clearance height | 710 mm | |
| Perimeter leg inset from table edge | 100 mm | |
| Extension leaf width (each) | 225 mm | |
| Floor clearance under base apron | 680 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 75 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 150 kg | |
| Seating capacity (closed configuration) | 4 people | |
| Seating capacity (extended configuration) | 6 people | |
| Tabletop surface scratch resistance | Class A for sintered stone | |
| Wood frame moisture content | 10% | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop panel | 12mm sintered stone with white grey-veined marble effect | |
|---|---|---|
| Table support frame | Solid natural light oak hardwood apron | |
| Support legs | Straight solid oak square legs with clear matte lacquer | |
| Tabletop edge trim | Solid oak edge banding matching frame finish | |
| Extension mechanism hardware | Zinc-plated steel slide glides with leaf lock tabs | |
| Foot pads | Non-slip plastic floor protector pads | |
| Surface finish (wood parts) | Matte clear polyurethane lacquer | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Extension mechanism operation | Two stored leaves fold out from tabletop, lock into place to form oval surface | |
|---|---|---|
| Leaf storage | Extension leaves integrate flush into closed round tabletop when not deployed | |
| Floor stability adjustment | Leveling feet on each leg compensate for up to 5mm uneven floor | |
| Surface performance | Sintered stone top resists heat up to 1200°C, stains, and liquid spills | |
| Assembly requirement | Legs attach to pre-assembled table frame with included hex hardware | |
| Locking function | Mechanical leaf locks prevent accidental fold during extended use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room use | Fits 6people for daily meals and casual family gatherings | |
|---|---|---|
| Apartment open-plan dining areas | Compact closed size fits small urban dining zones near living spaces | |
| Combined living-dining balcony spaces | Stable construction suitable for covered indoor balcony dining areas | |
| Small home entertaining use | Extended surface provides additional serving space for guest dinners | |
| Matching with spindle-back oak dining chairs | Designed to coordinate with light wood slat-back dining chair sets |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 71-3:2019 | Safety of toys - Migration of certain elements, applicable for food contact surfaces |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for frame quality inspection | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture | |
| GB/T 4897.3-2003 | Particleboard requirements for any engineered wood components used in base |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for frame quality inspection; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; 3. GB/T 4897.3-2003: Particleboard requirements for any engineered wood components used in base; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
