Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1830 × 910 × 762 mm | |
|---|---|---|
| Tabletop thickness | 40 mm | |
| Apron to floor leg clearance | 673 mm | |
| Leg cross-section dimension | 60 x 60 mm | |
| Leg inset from table corner | 150 mm | |
| Apron height below tabletop | 89 mm | |
| Edge bevel radius | 12 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 65 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 150 kg | |
| Per-leg vertical static load rating | 100 kg | |
| Finish liquid spill resistance duration | 24 hours | |
| Wobble resistance joint rating | 1000 lateral cycles | |
| Recommended maximum diner count | 6 people | |
| Seating capacity clearance per diner | 610 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop construction | Solid natural oak planks, edge-glued, matte UV-cured clear finish | |
|---|---|---|
| Table leg construction | Solid square-section oak, eased corners at apron joints | |
| Apron construction | Solid oak rails matching tabletop finish, attached to legs at corners | |
| Joint reinforcement | Hidden metal corner brackets with wood screw connectors | |
| Floor protection pads | 5mm thick non-slip felt pads affixed to each leg base | |
| Finish coating thickness | 0.15 mm | |
| Wood moisture content | 10% | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Structural design | Fixed non-extending rectangular frame with no moving parts | |
|---|---|---|
| Under-table access | Open unobstructed leg space for all six seating positions | |
| Assembly requirement | Knock-down (KD) assembly attaching legs and apron to tabletop | |
| Surface maintenance | Wipe-clean matte finish resistant to common food and drink stains | |
| Floor compatibility | Suitable for hard tile, wood, and low-pile carpeted surfaces | |
| Seating configuration | Accommodates two chairs on each long side, one chair on each short end | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Serves 6 people for daily family meals and casual dinner gatherings | |
|---|---|---|
| Open-plan kitchen dining area | Light natural oak finish complements Nordic, modern, and Scandinavian interior styles | |
| Small apartment dining nook | Compact 910mm depth fits efficiently in limited floor space without crowding | |
| Cafe and casual restaurant use | Durable solid wood construction withstands regular daily commercial use | |
| Open-plan living room display | Serves as a central accent piece for tabletop decor and seasonal styling |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 Furniture - Strength, durability and safety - Requirements for domestic tables | Applicable for structural strength and safety performance testing for residential use | |
|---|---|---|
| EN 13722:2004 Furniture - Test methods for surfaces - Assessment of resistance to cold liquids | Applicable for finish spill resistance verification |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable for dimensional tolerance, structural stability, and finish quality inspection | |
|---|---|---|
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applicable for formaldehyde emission verification for indoor residential use |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable for dimensional tolerance, structural stability, and finish quality inspection; 2. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applicable for formaldehyde emission verification for indoor residential use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
